Description
The Electromechanical Exit Bar (EMB) is engineered for application on magnetically locked, non-fire-rated doors, or as an initiating device for delayed egress systems. Activation of the bar triggers internal switches that unlock the door. Optional waterproof switches extend its usability to outdoor environments, complying with code requirements for “no special tools or knowledge.”
**Product Features**
– Innovative low-profile design requires just 1/4″ displacement for activation
– Available in three standard lengths: 36″, 42″, or 48″
– Can be field-cut to fit non-standard openings up to 48″ wide
– Compatible with the mounting patterns of TSB-3 and DSB
– Easily retrofits to most competitor mounting patterns
– Activates a DPDT 5 Amp rated output when pressed, allowing for free egress or triggering delay on exit delay timers
– Four individual switches ensure reliable, redundant operation
– Rugged all-metal construction
– Includes a 16 ft. (4.8m) 22AWG 6-conductor cable and armored door cord
– UL Listed
– Backed by a MagnaCare® lifetime replacement, no-fault warranty
**Specification Data**
– Operating Temperature Range: -4 to +185°F (-20 to +85°C)
– Shipping Weight: 7 to 9 lbs, dependent on length
