Description

High-definition infrared outdoor vandal-resistant dome cameras offer a seamless upgrade to HD surveillance using existing coaxial cabling, eliminating the expensive need for Ethernet cable installation. These advanced HD security cameras come equipped with a range of premium features, including Day/Night functionality, motion detection, defogging capabilities, and infrared illuminators, which vary according to the model. Variants include box cameras, indoor domes, outdoor vandal domes, and outdoor bullet cameras. Easy setup is achieved via OSD using the integrated joystick or coaxial control with HD digital video recorders (DVRs). With low power usage, compact designs, and transmission reach of up to 1,640 feet, this camera series stands out in the security industry.

Camera
Night Vision Distance98.43 ft
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66
NDAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Illumination0.01 lux
Maximum Video Resolution1600 x 1200

Environmental Conditions
Maximum Operating Temperature131°F (55°C)
Minimum Operating Temperature-22°F (-30°C)
Operating Humidity90%

Exposure
Longest Shutter Speed1 Second
Shortest Shutter Speed1/12000 Second

General Information
Brand NameHanwha Vision
ManufacturerHanwha Group
Manufacturer Part NumberSCV-6085R
Product ModelSCV-6085R
Product Name2MP Analog IR Vandal Dome Camera
Product SeriesHD+
Product TypeSurveillance Camera

Lens
Focal Length3.2-10 mm
Lens IncludedYes
Maximum Focal Length10 mm

Miscellaneous
FeaturesAlarm Triggering, Back Light Compensation (BLC), Built-in IR LED, Day/Night, Defog, Digital Noise Reduction, Digital Wide Dynamic Range (D-WDR), Highlight Compensation (HLC), Motion Detection, Privacy Masking, White Balance
Impact Protection RatingIK10
Indoor/OutdoorIndoor, Outdoor

Others
ADI Part Number ReplacesSQ-SCV6083R
Model Number ReplacesSCV-6083R

Physical Characteristics
ColorWhite
Color FamilyWhite
DurabilityDustproof, Impact Resistant, Vandal Resistant, Waterproof
Form FactorDome
Product ColorIvory
Weight (Approximate)1.58 lb

Power Description
Input Voltage12V DC, 24V AC

Product Information
Diameter5.4"
Mount TypePendant Mount

Storage
Recording FormatsHD

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution2MP
Field of ViewH : 110.2°(Wide) ~ 32°(Tele) V : 55.4°(Wide) ~ 18°(Tele) D : 128.4°(Wide) ~ 36.6°(Tele)
HD RecordingYes
Lens TypeVarifocal
Maximum Aperturef/1.6
Maximum Frame Rate30 fps
Minimum Focal Length3.2 mm
Night VisionYes
Optical Zoom3.1x

Video
Analog Video Signal FormatAHD, CVBS
