Description
The AtlasIED AH66-12T-BSG “stadium horn” speaker system is a superb solution for precise sound projection in environments demanding full-range audio reproduction, outstanding intelligibility, and elevated sound pressure levels. This versatile audio system is perfect for applications such as football stadiums, sports arenas, baseball fields, convention centers, and auditoriums.
Its robust, weather-resistant construction includes a strategic multi-screen configuration to shield internal components from moisture. A perforated aluminum screen protects the expansive horn opening, while a secondary screen guards the high-frequency driver, and a third, finely perforated screen secures the 12″ cast frame woofer. Additionally, a “weep” hole at the rear of the large horn “bell” facilitates the evaporation of any internal condensation.
**FEATURES**
– The constant directivity design ensures a controlled audio coverage pattern of 65° horizontal by 65° vertical in the 2kHz octave band.
– Features a driver complement with a 12″ cast frame woofer and a concentrically mounted 1″ exit compression driver linked to a 65°H x 65°V high-frequency horn.
– Boasts an efficiency rating of 102dB (1W/1m).
– Comes with a heavy-duty mounting bracket for simple installation on nearly any flat surface.
– Achieves a maximum output of 125dB (rated power @ 1M).
– Finished in an attractive neutral battleship gray.
