Leviton 47613-EZ6 EZ-RJ45 CAT6 Plug, Clear

Name: Leviton 47613-EZ6 EZ-RJ45 CAT6 Plug, Clear
Brand: Leviton
SKU: 47613-EZ6
Availability: InStock

In Stock

Special Order

$1.68

Transparent casing for wire sequence inspection
Connector opening facilitates cable feed-through for precise crimping
8-conductor modular connector
Accommodates insulated conductors with an outer diameter ranging from 0.037" to 0.042" (0.94mm to 1.07mm)
Maximum cable outer diameter: 0.275" (6.985mm)
Durability: Supports up to 1000 insertion/extraction cycles
Compatible with both solid and stranded cable types
Post-installation, test the connector-plug connection using the Modular Plug Terminated Link methodology as specified in ANSI/TIA-568.2-D

SKU: 47613-EZ6 Categories: Cable Connectors, Data Comm & Networking, Network Cable Connectors Brand: Leviton

Description

The EZ-RJ45 Cat 6 Plug is designed with innovative openings that enable wires to be inserted and extended through the front, enhancing network performance, facilitating wire sequence verification, and eliminating wasted connectors, crimps, and faulty terminations.

Certifications
TAA Compliant	No

General Information
Brand Name	Leviton
Manufacturer	Leviton Mfg. Company, Inc
Manufacturer Part Number	47613-EZ6
Packaged Quantity	50
Product Line	EZ-RJ45
Product Name	EZ-RJ45 Cat 6 Plug
Product Series	EZ
Product Type	Network Connector

Interfaces/Ports
Connector Type	RJ-45 Network - Male

Miscellaneous
Features	Stranded

Physical Characteristics
Color	Clear
Height	0.5"
Product Color	Clear
Product Material	Polycarbonate
Width	0.5"

Product Information
Length	0.9"

Technical Information
Connector Details	1 x 8-pin RJ-45 Network Male
Contact Plating	Gold
