Kantech VC-485 Multi-Function RS-232 to RS-485 Communication Interface

Name: Kantech VC-485 Multi-Function RS-232 to RS-485 Communication Interface
Brand: Kantech
SKU: VC-485
Availability: InStock

In Stock

Special Order

$213.41

This product offers the following key features for the security and access control industry:

- Facilitates the conversion from RS-232 to RS-485 communication
- Supports integration with up to 32 Kantech access control panels
- Utilizes UTP cabling for connectivity
- Operates with either 5 VDC or 12 VDC power supply
- Extends communication range up to 1,200 meters (4,000 feet)
- Achieves extended communication distance up to 5,486 meters (18,000 feet) when two units are connected sequentially
- Allows for back-to-back connection of two units to enhance the RS-485 communication bus

SKU: VC-485 Categories: Access Control, Software & Licenses Brand: Kantech

Description

The VC-485 Communication Interface serves as a versatile RS-232/RS-485 protocol converter, ideal for linking PCs to KT-100, KT-200, or KT-300 controllers. With a potential bus length of up to 5 km (18,000 ft) when using a line repeater, this device offers extensive connectivity for industrial communication systems. For EntraPass applications utilizing Ethernet Grade 3, unshielded, twisted pair cable, such as Belden #1227A, the maximum length is 1,200 m (4,000 ft). Additionally, two VC-485 units can be configured back-to-back to function as a line repeater, further extending RS-485 communication capabilities.

General Information
Brand Name	Kantech
Manufacturer	Johnson Controls
Manufacturer Part Number	VC-485
Product Name	Multi-Function Communication Interface
Product Type	Multi-Function Communication Interface

Physical Characteristics
Application/Usage	Controller
