Description
Introducing the single gang panic station equipped with a latching push button switch, designed to stay active or inactive until pressed again. This versatile contact configuration ensures seamless integration with a wide range of security systems.
Key Features
Standard Features
- Stainless steel wall plate suitable for single gang installations, engineered to be weather-resistant and compliant with IP65 standards
- 1-1/2″ red mushroom button for emergency situations
- Plate marked with “EMERGENCY PUSH FOR HELP” for rapid assistance requests
- Alternate action switching mechanism for enhanced control
Available Options
- Wall plate: Offers a variety of finishes and widths; please specify requirements when ordering
- Illumination: LED options with extended lifespan available in 6V, 12V, 24V, 120V; specify requirements when ordering
- GR Guard Ring for additional safety
- LUC Lift-up cover for added protection
Technical Specifications
Certifications & Listings: Conforms to IP65 standards
Electrical Specifications:
- Compatible with any combination of Normally Open (N/O) and Normally Closed (N/C) contact pairs
- Contacts rated at 10A for 5 VDC or 120 VAC applications
- Switch connections are made using screw terminals
- Switch depth behind the plate: 2-1/2 inches
Operating Temperature: Ranges from -13°F to +158°F (-25°C to 70°C)
