Brand: Hikvision

Hikvision DS-K7P04 Stainless-Steel Touchless Exit Button, White/Green/Red LED Status Indicator

Name: Hikvision DS-K7P04 Stainless-Steel Touchless Exit Button, White/Green/Red LED Status Indicator
Brand: Hikvision
SKU: DS-K7P04
Availability: InStock

in stock

In Stock

$28.79

Current Rating: 1 A at 30V DC, 0.5 A at 125V AC
Power Consumption: 20mA in Standby Mode, 50mA in Active Mode
Contact Configuration: NO/NC/COM

SKU: DS-K7P04 Categories: Access Control, Egress Devices, Request to Exit Devices Brand: Hikvision

Description

The DS-K7P04 exit button is a touchless switch designed specifically for various types of narrow doorframes. It features an aluminum panel and supports an inductive distance ranging from 40 mm to 100 mm.

Current Rating: 1 A @ 30 VDC, 0.5 A @ 125 VAC
Standby Current: 20mA, Operating Current: 50mA
Contact Options: NO/NC/COM
Maximum Inductive Distance: 1.57″ to 3.94″ (40 mm to 100 mm)
Input Voltage: 12 VDC

Certifications
TAA Compliant	No

Environmental Conditions
Maximum Operating Temperature	122°F (50°C)
Minimum Operating Temperature	-4°F (-20°C)

General Information
Brand Name	Hikvision
Manufacturer	Hikvision
Manufacturer Part Number	DS-K7P04
Product Model	DS-K7P04
Product Name	DS-K7P04 Exit Button
Product Type	Touch-free Button

Physical Characteristics
Application/Usage	Door
Color	Silver
Depth	1.5"
Height	3.5"
Material	Stainless Steel
Product Material	Aluminum
Weight (Approximate)	4.16 oz
Width	1.4"

Power Description
Input Voltage	120V AC, 12V DC, 30V DC

Product Information
Print/Message	Exit
