Brand: Linear

Linear NBT125-W 125 kHz Indoor/Outdoor Proximity Reader, Includes 2-N-1 Single Gang and Mullion Mounting Hardware

Name: Linear NBT125-W 125 kHz Indoor/Outdoor Proximity Reader, Includes 2-N-1 Single Gang and Mullion Mounting Hardware
Brand: Linear
SKU: 825-01257
Availability: InStock

in stock

In Stock

$104.52

Frequency: 125 kHz for contactless proximity access control
Installation: Versatile reader suitable for metal door and window frames, single-gang electrical boxes, and flat surfaces.
Dimensions for Mullion: 1.48" width x 4.74" height x 0.54" depth (37.5 mm x 120 mm x 13.7 mm)
Dimensions for Single-Gang: 2.99" width x 4.74" height x 0.54" depth (76.2 mm x 120 mm x 13.7 mm)
Certifications: Compliant with FCC, ICC, CE, UL Standard 2942, and IP67 standards
Reading Distance: Up to 3 inches (76 mm) from target
Cabling Requirements: Minimum 24 AWG, multiconductor, stranded wiring with an overall foil shield
Data Output Format: Supports Wiegand protocol
Temperature Range: Functional in temperatures from -40° F to 149° F (-40° C to +65° C)
Audio Feedback: Integrated standard beeper for audio signaling

SKU: 825-01257 Categories: Access Control, Keypads & Readers, Proximity Readers Brand: Linear

Description

125 kHz Access Control Reader for Indoor & Outdoor Use. Includes Mullion and Single Gang Mount Options.

Product Overview

The NBT125-W is compatible with all Linear 125 kHz access cards and key fobs and supports a wide range of access credentials from manufacturers like HID, AWID, and Farpointe (HAF).

This reader outputs data in the Wiegand format, ensuring compatibility with the majority of existing access control panels.

2-in-1: Supplied with mounting hardware for both single-gang and mullion installation.

IP67 rated, suitable for both indoor and outdoor environments.

General Information
Brand Name	Linear
Manufacturer	Nice S.p.A.
Manufacturer Part Number	825-01257
Product Model	NBT125-W
Product Name	NBT125-W Access Reader
Product Type	Card Reader Access Device

Interfaces/Ports
Network (RJ-45)	No
Wiegand	Yes

Miscellaneous
Compatibility	125 Proximity Credentials, AWID Models:, CLM125-A, CLM125-ACKEYFOBS:, CLM125-H, CLM125-HC, HID Models:, ISO CARDS:, ISO125-A, ISO125-ACCLAMSHELL CARDS:, ISO125-H, ISO125-HC, KFB125-A, KFB125-AC, KFB125-H, KFB125-HC
Indoor/Outdoor	Indoor, Outdoor
Package Contents	NBT125-W Access Reader Mullion and Single-Gang Mounts with Adapter Plate Installation Hardware

Others
ADI Part Number Replaces	LN-EL364MPB
Model Number Replaces	EL36-4MPB

Physical Characteristics
Application/Usage	Door, Indoor, Outdoor
Color	Black
Depth	0.5"
Form Factor	Gang Box Mount, Mullion Mount
Height	4.7"
Width	1.4"

Power Description
Input Voltage	12V DC, 14V DC, 8V DC

Technical Information
Bluetooth	No
Host Interface	Wiegand
Identification Method	Proximity
Operating Range	3"
Wireless LAN	No

Warranty
Limited Warranty	Lifetime
