Brand: Altronix

Altronix MAXIMAL3RD Power Distribution Unit, 12V DC/24V DC at 6A, 16 Ptc Out, Ra

Name: Altronix MAXIMAL3RD Power Distribution Unit, 12V DC/24V DC at 6A, 16 Ptc Out, Ra
Brand: Altronix
SKU: MAXIMAL3RD
Availability: InStock

in stock

Special Order

$632.68

Sixteen (16) independently controlled power outputs, configurable for PTC-protected 12V DC and/or 24V DC applications.
Individually configurable for Mag Lock/Strike (Fail-Safe, Fail-Secure) with solid-state PTC protection.
Equipped with thermal and short circuit protection featuring auto-reset functionality.
Supervision capabilities include monitoring for AC failure and low battery conditions.
Fire alarm disconnect function is individually selectable, either latching or non-latching, for any or all outputs.
Fire alarm disconnect feature.
Integrated battery charger suitable for sealed lead acid or gel-type batteries.
Seamless transfer to standby battery power.

SKU: MAXIMAL3RD Categories: Batteries & Power Supplies, Power Distribution Units, Power Management Brand: Altronix

Description

Power Supply/Charger with access control power distribution – Features 16 PTC outputs offering 12VDC or 24VDC power at 6 amps. Each output can be configured for Fail-Safe or Fail-Secure mode, with fire alarm disconnect options per output. Includes AC and battery monitoring housed in a 2U EIA 19″ Rack Mount Chassis with 115VAC input.

Certifications
NDAA Compliant	Yes

General Information
Brand Name	Altronix
Manufacturer	Altronix Corporation
Manufacturer Part Number	MAXIMAL3RD
Packaged Quantity	1
Product Condition	New
Product Line	Maximal
Product Model	MAXIMAL3RD
Product Name	PDU
Product Type	PDU

Physical Characteristics
Depth	8.5"
Form Factor	Rack Mount
Height	7.3"
Weight (Approximate)	12.85 lb
Width	12.5"

Power Description
Input Voltage	120V AC
Output Current	6A

Technical Information
Output Voltage	12V DC, 24V DC

Warranty
Limited Warranty	Lifetime
