Description

Over 20 million units sold – the reliable UPS choice for IT professionals

The award-winning APC Smart-UPS® stands as the global leader in uninterruptible power supply solutions for server, storage, and network protection. Trusted by industry experts to safeguard critical data and equipment from power interruptions, it delivers dependable and clean network-grade power. Renowned for exceptional reliability and manageability, Smart-UPS offers outstanding efficiency across low, medium, and high load levels, making it an ideal choice for modern multi-core and virtualized servers with varying power demands. Available in diverse form factors – tower, rack mount, and convertible – there’s a Smart-UPS model suited for every application and budget. Rack-mounted Smart-UPS units are perfect for powering blade or high-density servers in distributed power protection settings, whether for primary or redundant support. For years, Smart-UPS models have defined the standard for network and server UPS solutions. These units boast a 16-segment LED display, advanced automatic voltage regulation (AVR), and deliver pure sine wave output when on battery power. Enhanced manageability is offered via the Smart-Slot interface, an internal slot designed for optional accessory card installations. The extended run Smart-UPS XL model allows for the addition of external battery packs, extending runtime from minutes to hours, essential for comprehensive voice and data network protection. The entry-level Smart-UPS SC provides an economical solution for small to medium-sized businesses seeking to protect switches, networking hardware, and point-of-sale (POS) equipment.

Battery Information
Battery CharacteristicsSpill-proof, Maintenance-free
Battery ChemistryLead Acid
Typical Battery Recharge Time3-Hour

General Information
Brand NameAPC by Schneider Electric
ManufacturerSchneider Electric SA
Manufacturer Part NumberSMX2000LVNC
Product LineSmart-UPS
Product NameSmart-UPS X 2000VA Rack/Tower LCD 100-127V with Network Card
Product TypeLine-interactive UPS

Interfaces/Ports
Network (RJ-45)Yes

Management
Network ManagementSNMP Manageable

Miscellaneous
Environmental CertificationREACH, RoHS
Environmentally FriendlyYes
Package ContentsSmart-UPS X 2000VA Rack/Tower LCD 100-127V with Network CardCD with softwareDocumentation CDInstallation guideNetwork management cardRack mounting bracketsand more below, ack mounting support rails, Rack mounting hardware, Smart UPS signalling RS-232 cable, USB cable

Physical Characteristics
ColorBlack
Color FamilyBlack
Depth19"
Form FactorRack Mount
Height17"
Product ColorBlack
Rack Height4U
Weight (Approximate)85.19 lb
Width7"

Power Description
Input Voltage110V AC
Plug/Connector TypeNEMA 5-20P
Surge Energy Rating540 J
Waveform TypeSine Wave

Technical Information
Hot SwappableYes
Number of Batteries1
Number of Battery & Surge Outlets10
Output Voltage24V DC
Receptacle Detail1 x NEMA 5-15R, 3 x NEMA 5-20R, 6 x NEMA L5-20R
Receptacle TypeNEMA 5-15R, NEMA 5-20R, NEMA L5-20R
Transfer Time4 ms

Warranty
Additional Warranty Information3 years repair or replace (excluding battery) and 2 years for battery
Limited Warranty3-Year
