Description

Over 20 Million Units Sold – The Trusted UPS Solution
The renowned APC Smart-UPSĀ® series is the global leader in uninterruptible power supply (UPS) systems for servers, storage, and network power protection. These units ensure the safeguarding of critical data and equipment from power disturbances by delivering clean, reliable network-grade power. Known for their exceptional reliability and manageability, Smart-UPS systems boast high efficiency across low, medium, and high load levels, making them perfect for modern multi-core or virtualized servers with variable load requirements. Offered in a range of form factors, including tower, rack mount, and convertible options, there’s a Smart-UPS model suitable for any application and budget. Rack-mounted Smart-UPS units are particularly suited for powering blade or high-density servers in distributed power protection scenarios, serving as primary or redundant protection. Widely regarded as the standard for network and server UPS systems, Smart-UPS products feature a 16-segment LED display, extended range automatic voltage regulation (AVR), and pure sine wave output when on battery power. Enhanced management is possible through the Smart-Slot interface, an internal slot for optional accessory card installation. The extended run models, Smart-UPS XL, support external battery packs to expand runtime from minutes to the extended durations required for converged voice and data network applications. For small and medium-sized enterprises, the entry-level Smart-UPS SC offers a cost-effective solution to protect smaller network switches, networking gear, and point-of-sale (POS) equipment.

Battery Information
Battery CharacteristicsSpill-proof, Maintenance-free
Battery ChemistryLead Acid
Typical Battery Recharge Time3 hrs

Environmental Conditions
Sound Emission55 dB
Thermal Dissipation43.96 W

General Information
Brand NameAPC by Schneider Electric
ManufacturerSchneider Electric SA
Manufacturer Part NumberSMX2200HV
Product LineSmart-UPS
Product NameSmart-UPS X 2200VA Rack/Tower LCD 200-240V
Product SeriesSMX
Product TypeLine-interactive UPS

Management
AlarmConfigurable Delay, Low Battery, On Battery

Miscellaneous
Environmental CertificationRoHS
Environmentally FriendlyYes
Package ContentsSmart-UPS X 2200VA Rack/Tower LCD 200-240V CD with softwareDocumentation CDRack mounting support railsSmart UPS signalling RS-232 cableUSB cableUser manual

Physical Characteristics
ColorBlack
Color FamilyBlack
Depth19"
Form FactorRack Mount
Height17"
Product ColorBlack
Rack Height4U
Weight (Approximate)38.64 lb
Width7"

Power Description
Input Voltage208V AC
Plug/Connector TypeBritish BS1363A, IEC 320-C20
Surge Energy Rating645 J
Waveform TypeSine Wave

Software
Software IncludedPowerchute Serial Edition

Technical Information
Number of Battery & Surge Outlets12
Output Voltage12V DC, 24V DC
Receptacle Detail2 x IEC 320-C19, 2 x IEC Jumper, 8 x IEC 320-C13
Receptacle TypeSchuko CEE 7/EU1-16P

Warranty
Additional Warranty Information3 years repair or replace (excluding battery) and 2 years for battery
Limited Warranty3 Year
