Description
**SCLASS™ Unified Power Systems** are designed to integrate FlexPower® modules with SWH iSTAR™ access hardware within a single, compact, and listed enclosure.
This system offers a dual voltage access control capability, supporting both 12V and 24V DC. Two C8 control modules provide sixteen access control inputs that can be activated via voltage or dry contact. These modules also feature sixteen programmable outputs for fail-safe or fail-secure operation at 12 or 24 VDC, managed by the built-in fire alarm interface circuit on the FPO. Additionally, the system includes two D8 modules that offer sixteen auxiliary outputs, each configurable for either 12 or 24 VDC.
The SCLASS enclosures are crafted from painted steel and feature a removable backplate, a lock with two keys, and a tamper switch.
**System Highlights**
– **FPO Offline Power Supply**
– 120 or 230 VAC input
– 12 and 24 VDC outputs
– Built-in Fire Alarm Interface
– Continuous and resettable DC
– **Distributed Outputs**
– Sixteen auxiliary outputs, each fused at 3A
– Sixteen lock control outputs, each fused at 3A
**Expansion Capabilities**
– Increased power and multiple voltage options
– Additional distribution outputs
– Network monitoring and reporting
**Lifetime Warranty**
**Enclosure Features**
– **Labor-Saving Design**
– Pre-wired power sections
– Pre-punched knockouts
– Removable backplate for easy installation
– Pre-defined hole pattern for power section
– Access panels mount on threaded studs without drilling
**Additional Benefits**
– Ample wire management space
– 4.5″ enclosure depth accommodates battery sets
– Standard tamper switch, lock, and dual key set
– Includes mounting hardware for access boards
