Description
The RGM75 Series is a powerful 75W integrated 2U rackmount power system that supports system power, lock power, and access control controllers.
RGM enclosures are designed to accommodate up to two access control controllers and multiple LifeSafety Power FlexPower® devices, forming a comprehensive access control system. This system can manage up to four doors as a standalone unit or can be expanded to control additional doors when interconnected. The specific LSP power modules vary based on the RGM model number, while access control controllers are specified by the integrator according to project needs.
Flexible configuration options include single (12V or 24V DC) or dual voltage operations (12V and 24V DC), comprehensive power distribution and control, and individual output protection via fuses or class 2 power limiting. The system features buffered lock control, remote reporting, and diagnostic testing capabilities. Each LSP output is safeguarded against electrical surges, with SurgeShield™ technology, and is individually configurable for available DC voltages, supporting both failsafe and failsecure operations with a fire alarm interface.
Optional network monitoring features provide detailed information on operational fault status, power supply output, battery charging voltage, current, and fire alarm input status. These capabilities allow for automated and scheduled status updates, as well as remote diagnostic servicing and battery load tests, significantly reducing the need for on-site maintenance.
The unit is suitable for installation within a standard four-post EIA 19-inch electronics rack, with a maximum depth capacity of 36 inches.
Rackmount Features
- Integrated access system with power distribution for both lock and system control
- Compartmentalized design for enhanced reliability
- Rack drawer slide assembly facilitates controller wiring and maintenance
- Comprehensive wire management including tie-down points and articulating brackets
- Supports 120 or 230V AC user-selectable input, compatible with data center power systems
Configuration Options
- Options for single voltage or dual 12 and 24VDC voltages covering all access functions
- Power distribution supports direct (D8), buffered (C8), or managed (M8) configurations
- Select individual outputs for failsafe, failsecure, lock voltage, and fire alarm interface
- High-capacity battery charging capabilities
- Automotive fuses ensure easy serviceability and replacement
- Facilitates door expansion with additional Gemini drawers
- Companion battery housing for rackmount use available (part number RBE)
Network Monitoring
- Monitor and alert for power supply status, battery operation, and fault detection
- Conduct remote tests for battery runtime, low battery, and service alerts
- Monitor and power cycle individual outputs with the M8N model
- Monitor and send alerts based on external room temperature
