Description
The UTP jack module for Category 5e/Class D applications, designed with an 8-position interface, is engineered to terminate solid 4-pair cables ranging from 24 to 22 AWG with a 100-ohm impedance. This jack module does not require a punchdown tool for installation and employs a forward motion termination technique. This method is specifically designed to optimize signal integrity by preserving the cable’s pair geometry while minimizing conductor untwist. The termination cap is color-coded red to indicate Category 5e compliance and features a universal label that supports both T568A and T568B wiring configurations.
