Dahua DH-TAM1GT1GT-30 Single-Port PoE+ Midspan

Category: PoE Injectors

Dahua DH-TAM1GT1GT-30 Single-Port PoE+ Midspan

Name: Dahua DH-TAM1GT1GT-30 Single-Port PoE+ Midspan
SKU: DH-TAM1GT1GT-30
Availability: InStock

In Stock

Special Order

$41.99

Compatible with IEEE802.3af and IEEE802.3at Power over Ethernet (PoE) Standards
Adheres to IEEE802.3, IEEE802.3u, and IEEE802.3ab Networking Standards
Operates Across a Wide Temperature Range for Industrial-Grade Applications

SKU: DH-TAM1GT1GT-30 Categories: Data Comm & Networking, PoE Devices, PoE Injectors

Description

The DH-TAM1GT1GT-30 PoE+ Midspan is engineered to function in harsh temperature conditions and applications prone to lightning. This midspan features a single PoE+ (802.3at) port with an integrated power supply within a compact enclosure. It efficiently transmits both data and power over an Ethernet cable, simplifying the installation of IP cameras, wireless access points, or VoIP phones.

Environmental Conditions
Operating Relative Humidity (H-H)	10%-90%
Operating Temperature (T-T)	14-131°F

General Information
Brand Name	Dahua
Led Indicators	Yes
Manufacturer	Zhejiang Dahua Technology Co., Ltd.
Manufacturer Part Number	DH-TAM1GT1GT-30
Product Model	TAM1GT1GT-30
Product Name	PoE+ Midspan
Product Type	PoE Injector

Interfaces/Ports
Input Ports	10/100/1000Base-T
Output Ports	10/100/1000Base-T

Media & Performance
Network Technology	10/100/1000Base-T

Miscellaneous
Country of Origin	CN
Environmental Certification	WEEE
Environmentally Friendly	Yes

Network & Communication
Networking Standards	IEEE802.3af, IEEE802.3at

Physical Characteristics
Depth	2.4"
Height	1.2"
Weight (Approximate)	8.82 oz
Width	5.2"

Power Description
Input Voltage	120V AC, 230V AC
Maximum Frequency	60 Hz
Maximum Output Power	30W
Maximum Output Voltage	51V DC

Product Information
Protection Type	Lightning Protection

Warranty
Limited Warranty	3 Year
