Brand: Altronix

Altronix NetWay8BT Network Managed 802.3bt 4PPoE Midspan, 8-port, 10/100/1000, 90W max per port (480W total power), Battery Charging, 115/230VAC

Name: Altronix NetWay8BT Network Managed 802.3bt 4PPoE Midspan, 8-port, 10/100/1000, 90W max per port (480W total power), Battery Charging, 115/230VAC
Brand: Altronix
SKU: NETWAY8BT
Availability: InStock

in stock

Special Order

$1,327.27

Compliant with IEEE 802.3af (15W), IEEE 802.3at (30W), and IEEE 802.3bt standards.
Offers up to 90W power per port, with a total power capacity of 480W.
Equipped with eight (8) Ethernet ports for connecting cameras and edge devices.
Provides local or remote access to vital information through LAN/WAN connections.
Features an event log for tracking historical data.
Includes built-in IP network management for remote camera reset and monitoring.
Supports speeds of 10/100/1000 Mbps.
Features LEDs for port status indicators.
Automatically detects and protects legacy non-PoE cameras and devices.
Offers real-time power diagnostics with email alerts and Windows Dashboard notifications.

SKU: NETWAY8BT Categories: Data Comm & Networking, PoE Devices, PoE Injectors Brand: Altronix

Description

The Altronix NetWay8BT is an 8-port network-managed PoE midspan housed in a 1U rack-mount enclosure. This device delivers PoE, PoE+, and High PoE with up to 90W per port, compliant with 802.3bt standards, with a total power output of 480W. It supports data transmission rates of 10/100/1000 Mbps over distances of up to 100 meters. Additional features include a built-in battery charger for backup power applications and integrated LINQ Technology for remote monitoring, control, and diagnostics via network connectivity.

Certifications
TAA Compliant	No

Environmental Conditions
Operating Temperature (T-T)	-4-104°F
Storage Temperature (T-T)	-40-158°F

General Information
Brand Name	Altronix
Led Indicators	Yes
Manufacturer	Altronix Corporation
Manufacturer Part Number	NETWAY8BT
Product Line	NetWay
Product Model	NETWAY8BT
Product Name	8-Port Managed 802.3bt Midspan Injecto
Product Type	PoE Injector

Interfaces/Ports
Input Ports	8 x PoE
Output Ports	PoE

Media & Performance
Data Transfer Rate	10 Mbps, 100 Mbps, 1000 Mbps

Miscellaneous
Environmental Certification	UL
Environmentally Friendly	Yes

Network & Communication
Networking Standards	EEE 802.3af, IEEE 802.3at, IEEE802.3bt

Physical Characteristics
Depth	8.5"
Form Factor	Rack Mount
Height	8.5"
Rack Height	1U
Shipping Height	20.25"
Shipping Weight (Approximate)	7.7 lb
Shipping Width	12.5"
Weight (Approximate)	6.40 lb
Width	1.6"

Power Description
Input Voltage	120V AC, 230V AC
Maximum Input Current	5.50 A
Maximum Output Power	480W

Product Information
Length	19.1"

Warranty
Limited Warranty	Lifetime
