Description
Description
The PS-DATK and PS-SATK manual pull stations are designed with premium die-cast metal construction, offering robust and reliable performance for fire alarm systems. These pull stations are available in single or dual action configurations, equipped with an SPST switch and terminal strip connections for seamless integration. The normally open contact, which closes upon activation of the station, is rated for 1 amp at 125 VAC or 30 VDC, featuring gold-plated contacts to prevent corrosion. All models in this series have been rigorously tested and are in full compliance with the latest American with Disabilities Act (ADA) standards, certified by UL.
Features
- UL Listed for fire safety standards
- CSFM Certification for performance
- MEA (BSA) approval for building safety
- ADA Compliance for accessibility
- Weatherproof model certified for outdoor environments
- Available in single or dual action configurations
- Easy terminal strip connections
- Compatible key reset with Silent Knight enclosures
- Optional surface mount backboxes
- High-gloss red enamel finish on durable die-cast metal
- Gold-plated contacts for corrosion resistance
Operation
The single-action pull stations activate by pulling the handle downward until it locks, providing high visibility from up to 50 feet away. Each unit includes a scored acrylic break rod for specific applications. To reset, unlock the station with a key, return the handle to its original position, and relock.
Dual-action models operate with the PUSH bar which rotates inward, allowing users to grasp the PULL handle with one hand. These models also include break rods and reset similarly to single-action models.
The weatherproof models come with a gasket and a die-cast metal backbox, tapped for 1/2″ conduit for surface mounting, making them ideal for exterior use.
