Description

Resideo is dedicated to delivering top-tier alarm communication solutions for the security sector. Our LTEM-P Communicators harness advanced LTE® technology, specifically crafted for IoT devices, to seamlessly interface with AlarmNet®.

Utilizing CAT-M1 LTE technology from leading carriers, these communicators offer superior signal strength and power efficiency, enhancing performance in challenging environments like underground and within structures. This cutting-edge LTE CAT-M1 technology is accessible wherever current LTE networks operate, ensuring robust and consistent connectivity.

The LTEM-P Communicators effortlessly integrate with customers’ security system control panels, transmitting alarms and messages to AlarmNet for relay to a central monitoring station.

**The LTEM-P Line features:**
– LTEM-PV (Verizon® network)
– LTEM-PA (AT&T® network)

**The LTEM-P Line also accommodates optional plug-in modules:**
– LTE CAT-1 Cell Radio Module for advanced cellular capabilities (model PROLTE series)
– Wi-Fi®/Z-Wave® Module for Wi-Fi Internet connection and home automation control (model PROWIFIZW)
– Dialer Capture Module for integrating with control panels that send Contact ID signals via Dialer (model PRODCM)
– Wi-Fi Module for Internet connectivity via Wi-Fi

General Information
Brand NameResideo
Card Type0% RH - non-condensing
ManufacturerResideo
Manufacturer Part NumberLTEM-PV
Product ModelLTEM-P
Product NameLTEM-PV Advanced Modular Communicator (VERIZON)
Product TypeBurglar Alarm Communicator

Miscellaneous
CompatibilityInterlogix NX-4, NX-6, NX-8, NX-8E DSC PC1616 , PC1832, PC1864, Total Connct 2.0, VISTA-128BP, VISTA-128BPE, VISTA-128BPT, VISTA-15P, VISTA-20P, VISTA-21iP w/internal communicator, VISTA-250BP, VISTA-250BPE, VISTA-250BPT
FeaturesAllows uploading and downloading of VISTA control panel data, Multi-function Test switch used to generate test messages, register the communicator with AlarmNet, enter Pairing mode (used during WiFi module installation), reboot the communicator, and to reset the communicator to factory default settings., Power supplied by a 9VDC Power Adapter (included), Quick connection to both Resideo control panels (ex. VISTA controls) and compatible non-Resideo (non-VISTA) control panels, Reports alarms and status messages via the Internet, Reports messages via cell as backup to Internet reporting (provided that the Communication Path includes cell), Supports both ECP and Bus connections to compatible control panels, Supports connection to the Internet via Ethernet cable or WiFi (WiFi requires installation of PROWIFIZW or PROWIFI module) – only one method can be used, Ethernet or WiFi, not both, Supports dynamic or static IP addressing, and installs behind firewalls without compromising network security (provided that the Communication Path includes IP), Supports Remote Services feature, which allows the end user to access their security system from their computer via a website. Availability of this service is controlled by the dealer via the web-based programming tool on the AlarmNet 360 website
Package ContentsLTEM-PV Advanced Modular Communicator (VERIZON) 9VDC Power Adapter

Network & Communication
Communication TechnologyLTE CAT1
EthernetYes
Sensor ConnectivityWireless

Others
ADI Part Number ReplacesLTE-IV
Model Number ReplacesLTE-IV

Physical Characteristics
Application/UsageRadio Communications
ColorWhite
Color FamilyWhite
Depth9.1"
Height9.1"|23.2 cm
Weight (Approximate)1.54 lb
Width2.2"|5.7 cm

Power Description
Input Voltage9V DC

Product Information
Installation TypeProfessional Install

Technical Information
Cellular Generation4G LTE
Connectivity TechnologyWireless
Wireless LANYes
