Description
The DVX-3266-4K 8×4+2 Presentation Switcher is a versatile audio, video, and control solution that eliminates the need for multiple pieces of equipment, offering a cost-effective, easy-to-install, and reliable alternative.
This compact 2U Presentation Switcher supports cutting-edge video technologies, delivering full 4K60 4:4:4 and HDR video on every output. With audio solutions from Crown, BSS, and dbx, it provides the renowned audio quality associated with Harman, and the integration of Dante audio enables network-based audio distribution.
The built-in NX processor offers advanced security features and technologies, including a mobile-responsive HTML5 web interface, an ICSLan isolated network, and automatic binding of DXLink endpoints.
The DVX 4K60 stands out with the industry’s lowest Total Cost of Ownership due to simplified support, maintenance, and configuration, alongside reduced hardware and cabling expenses.
Common Applications
The DVX-3266-4K is ideal for medium to large and complex conference rooms, classrooms, and auditoriums that benefit from 4K60 4:4:4 resolution. Its four DXLink inputs allow dual room support, enabling multiple collaboration spaces to share one DVX or accommodate situations where the AV rack is distant from source devices and displays. Its compact size is suitable for rooms or facilities with limited space, especially those with constrained equipment racks.
Features
- 4K60 4:4:4 Support – HDMI 2.0 and HDCP 2.2 Support – Offers the highest video quality over HDMI and category cable with scaled outputs.
- High Dynamic Range (HDR) and Deep Color Support – Compatible with HDR10 and 36-bit Deep Color.
- Simple Configuration and Support – HTML5 Web Interface with integrated status and troubleshooting features eliminates the need for proprietary configuration software. Internal network enables automatic endpoint configuration.
- Dante Audio – Provides 8 input channels and 8 output channels of IP audio.
- Crown DriveCore Amplifier – Delivers 120W per channel stereo at 4/8 ohms or 120W mono at 70/100 Volt.
- USB 2.0 – Transfers high-speed USB 2.0 data from conferencing cameras and storage devices without separate cables.
- DXLink™ Twisted Pair Inputs and Outputs – Facilitates audio, video, bi-directional control, USB 2.0, and Ethernet transmission up to 100m away via one twisted pair cable.
- All-In-One Device – Combines controller, matrix switcher, video scaler, audio signal processor, amplifier, and twisted pair distribution in a space-efficient 2U chassis.
- Simplicity & Reliability – Consolidates the need for multiple components, ensuring reliability and reducing configuration and programming costs.
- Low Total Cost of Ownership – Offers a consistent platform across various sizes, simplifying standardization on the DVX, thereby reducing costs for hardware, training, support, troubleshooting, and sparing.
- Unrivaled Network Security – Features Dual NICs for isolating AV equipment from the main network, IPv6, 802.1X for secure network access, LDAP integration with customizable user groups, syslog support, and encrypted IP communication through FIPS 140-2 validated cryptographic modules, ensuring robust security.
