Description

The CDi DriveCore Series represents a significant advancement in the field of amplification, offering a remarkable combination of high performance, comprehensive features, and cost-effectiveness. Leveraging technology from the top-tier Installed Sound amplifier series, the CDi DriveCore 2|300 is designed to seamlessly integrate into a wide range of small to medium-sized audio installations, such as restaurants, retail environments, and more. This 2-channel amplifier is engineered for user-friendly operation across multiple applications and features network control and monitoring, advanced DSP, a user-friendly front-panel interface, and the capacity to drive up to 100Vrms speaker loads without the need for a transformer. Additionally, the entire CDi DriveCore lineup is equipped with pre-configured JBL speaker tunings to facilitate faster and more efficient installations.

Audio
Maximum Frequency Response20 kHz
Minimum Frequency Response20 Hz
RMS Output Power600W
Total Harmonic Distortion (THD)0.4%

Certifications
TAA CompliantNo

Energy & Performance
Operating Power Consumption300W

General Information
Brand NameCrown by Harman
ManufacturerHarman International Industries, Inc
Manufacturer Part NumberCRN-CDI2X300VMUS
Product LineCDi DriveCore
Product Model2|300
Product NameAnalog Input, 2 Channel, 300W Per Output Channel
Product TypeAmplifier

Interfaces/Ports
Number of Analog Audio Inputs1
Number of Audio Inputs2

Miscellaneous
Environmental CertificationWEEE
Environmentally FriendlyYes
FeaturesAdvanced DSP on Inputs and Outputs, Color LCD Panel for Control and Monitoring, DriveCore Technology, Monitor and Control over Standard TCP/IP, Remarkable Performance and Reliability, Supports HiQnet Audio Architect Software, Works in 70/100V and Low Impedance

Network & Communication
EthernetYes

Physical Characteristics
ColorBlack
Depth12.3"
Height3.5"
Weight (Approximate)14.56 lb
Width19"

Power Description
Input Voltage100V AC, 240V AC

Technical Information
Audio Channels2
Impedance8 ohms

Warranty
Limited Warranty3 Year
