AMX FG1010-325-WHFX Multi-Format Decor Style Wall Plate Transmitter, White

Name: AMX FG1010-325-WHFX Multi-Format Decor Style Wall Plate Transmitter, White
Brand: AMX by Harman
SKU: FG1010-325-WHFX
Availability: InStock

in stock

Special Order

$664.30

Single-Cable Solution: Transmit both audio and video while delivering power over a single twisted pair cable
Versatile Connectivity: Multi-format analog port and HDMI port supporting legacy analog signals such as RGBHV, Component, S-Video, and Composite, along with digital signals like HDMI/HDCP, DisplayPort++, and DVI
Extended HDMI Transmission: Extend HDMI signals up to 100 meters, surpassing the limitations of standard HDMI cabling
Cost-Effective Cabling: Utilize standard twisted pair cable to save time and reduce installation costs; refer to the "Cabling for Success" white paper for detailed guidelines
Seamless Installation: Designed to fit into standard decor-style wallplates for easy installation
Integrated Power Solutions: Compatible with systems such as Enova DGX or DVX with DXLink inputs, or power injectors like PS-POE-AT-TC or PDXL-2, to enable Power over DXLink for remote powering (requires firmware v1.2.40 or above)
Point-to-Point Connectivity: DXLink wallplates can be directly connected to a DXLink receiver for a simplified point-to-point solution when using Power over DXLink

SKU: FG1010-325-WHFX Categories: Commercial Video Signal Distribution, Pro AV, Pro HDMI Switchers Brand: AMX by Harman

Description

Explore the efficiency and versatility of the AMX FG1010-325-WHFX Multi-Format Wall Plate Transmitter, a cutting-edge solution for audiovisual installations. This device enhances system configurations by transmitting audio, video, and power through a single twisted pair cable. It supports a diverse range of signals, including RGBHV, Component, S-Video, Composite, HDMI/HDCP, DisplayPort++, and DVI. With the ability to extend HDMI signals up to 100 meters, it significantly exceeds the limitations of conventional HDMI cables. The transmitter’s standard wallplate design ensures easy installation and is compatible with Enova DGX or DVX systems. Perfect for both legacy and contemporary technologies, this transmitter guarantees seamless integration and optimized performance in any setup. Upgrade your system now for enhanced connectivity and extended signal reach!

General Information
Brand Name	AMX by Harman
Manufacturer	AMX by Harman
Manufacturer Part Number	FG1010-325-WHFX
Product Model	DX-TX-DWP
Product Name	DXLink Multi-Format Decor Style Wallplate Transmitters
Product Type	Wallplate Transmitters

Miscellaneous
Features	DXLink Direct Connection When receiving Power over DXLink from the PS-POE-AT-TC or PDXL-2, DXLink Wallplates can be connected directly to a DXLink Receiver for a point-to-point solution, Easy Installation Mounts in standard decor style wallplates, Multi-Format Analog Port and HDMI Port Supports legacy analog signals-RGBHV, Component, S-Video, and Composite, and digital HDMI/HDCP, DisplayPort++ and DVI signals, Only One Cable Send audio and video, while passing power over one twisted pair cable, Power over DXLink Enabled Designed for use with Enova DGX or DVX systems with DXLink inputs, or PS-POE-AT-TC (FG423-84) or PDXL-2 (FG1090-170) to provide remotely located Power over DXLink (requires firmware v1.2.40 or above), Send HDMI signals up to 100 meters Extend the reach of the HDMI signals far beyond the capabilities of typical HDMI cabling, Standard Twisted Pair Cable Save time and effort in installation by leveraging cost effective twisted pair cable, see the Cabling for Success with DXLink white paper for more details

Physical Characteristics
Color	White
Depth	2-1/4"
Height	4-1/16"
Width	3-1/2"
