Description

The HD+ IR indoor dome cameras provide an ideal solution for upgrading surveillance systems to high-definition using existing coaxial cabling, eliminating the need for expensive Ethernet cable replacements. These advanced cameras feature a range of high-performance options such as Day/Night functionality, motion detection, defog technology, and IR illuminators, varying by model. Users can easily manage setup functions through the on-screen display controlled by a built-in joystick or via coaxial cable control with compatible HD+ DVRs. With their low power consumption, compact design, and transmission capabilities reaching up to 1,640 feet, these cameras offer a robust addition to any security lineup.

Camera
Night Vision Distance65.62 ft
Wide Dynamic RangeYes

Certifications
NDAA CompliantYes

Display & Graphics
Color SupportedColor, Monochrome
Maximum Video Resolution1600 x 1200

Environmental Conditions
Maximum Operating Temperature131°F (55°C)
Minimum Operating Temperature14°F (-10°C)
Operating Humidity90%

Exposure
Longest Shutter Speed1 Second
Minimum Illumination0.1 lux
Shortest Shutter Speed1/12000 Second

General Information
Brand NameHanwha Vision
ManufacturerHanwha Group
Manufacturer Part NumberSCD-6085R
Product LineWiseNet
Product ModelSCD-6085R
Product Name2MP Analog IR Dome Camera
Product SeriesAHD
Product TypeSurveillance Camera

Lens
Focal Length3.2-10 mm
Lens IncludedYes
Maximum Focal Length10 mm

Miscellaneous
FeaturesAlarm Triggering, Back Light Compensation (BLC), Built-in Mechanical ICR, Day/Night, Defog, Digital Noise Reduction, Digital Wide Dynamic Range (D-WDR), Gain Control, Highlight Compensation (HLC), Motion Detection, Privacy Masking, White Balance
Indoor/OutdoorIndoor

Network & Communication
Remote ManagementNo

Physical Characteristics
ColorWhite
Color FamilyWhite
Depth4.7"
Form FactorDome
Height3.9"
Product ColorIvory
Weight (Approximate)11.29 oz
Width4.7"

Power Description
Input Voltage12V DC, 24V AC

Product Information
Diameter4.7"
Mount TypeBackbox Mount, Ceiling Mount, Corner Mount, Flush Mount, Gooseneck Mount, Pendant Mount, Pole Mount, Wall Mount

Storage
Recording FormatsHD

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution2MP
Field of ViewH : 110.2°(Wide) ~ 32°(Tele) V : 55.4°(Wide) ~ 18°(Tele) D : 128.4°(Wide) ~ 36.6°(Tele)
HD RecordingYes
Lens TypeVarifocal
Maximum Aperturef/1.6
Maximum Frame Rate30 fps
Minimum Focal Length3.2 mm
Night VisionYes
Night Vision TypeColor
Optical Zoom3.1x

Video
Analog Video Signal FormatAHD, CVBS
