Description

The HD+ series offers outstanding 4MP (2560 x 1440) and 2MP (1920 x 1080) resolution, delivering exceptional image clarity and detail. This advanced technology not only outperforms traditional analog systems but also matches the resolution capabilities of network systems without any latency issues. The resulting images are remarkably clear and vibrant, making the 4MP HD+ series an ideal choice for mid to large-scale businesses and projects seeking a highly dependable surveillance system. Additionally, these cameras efficiently transmit 30fps with 4MP (QHD) video.

Camera
Night Vision Distance98 ft
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66
NDAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution1600 x 1200

Environmental Conditions
Maximum Operating Temperature131°F (55°C)
Minimum Operating Temperature-22°F (-30°C)
Operating Humidity90%

Exposure
Longest Shutter Speed1 Second
Shortest Shutter Speed1/12000 Second

General Information
Brand NameHanwha Vision
ManufacturerHanwha Group
Manufacturer Part NumberHCV-6070R
Product LineWisenet
Product ModelHCV-6070R
Product Name2MP Analog HD IR Outdoor Dome
Product SeriesHD+
Product TypeSurveillance Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length3.2-10 mm
Lens IncludedYes
Maximum Focal Length10 mm

Miscellaneous
FeaturesAutomatic White Balance, Back Light Compensation (BLC), Built-in IR LED, Day/Night, Defog, Digital Noise Reduction, Highlight Compensation (HLC), Motion Detection, Privacy Masking, Wide Dynamic Range
Impact Protection RatingIK10
Indoor/OutdoorIndoor, Outdoor

Network & Communication
Remote ManagementNo

Physical Characteristics
ColorWhite
Color FamilyWhite
Depth5.4"
DurabilityDustproof, Impact Resistant, Vandal Resistant, Waterproof
Form FactorDome
Height4.2"
Product ColorIvory
Weight (Approximate)1.58 lb
Width5.4"

Power Description
Input Voltage12V DC, 24V AC

Product Information
Diameter5.4"
Mount TypeBox Mount, Ceiling Mount, Pole Mount, Wall Mount

Storage
Recording FormatsFull HD
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution2MP
Field of ViewH : 110.2 ?(Wide) ~ 32 ?(Tele) / V : 55.4 ?(Wide) ~ 18 ?(Tele) / D : 128.4 ?(Wide) ~ 36.6 ?(Tele)
HD RecordingYes
Lens Mount TypeBoard Mount
Lens TypeVarifocal
Maximum Aperturef/1.6
Maximum Frame Rate15 fps
Minimum Focal Length3.2 mm
Night VisionYes
Night Vision TypeInfrared
Optical Zoom3.1x

Video
Analog Video Signal FormatAHD, CVBS, CVI, TVI

Warranty
Limited Warranty3 Year
