Description

The new Q series PTZ cameras have achieved a weight reduction of up to 55% for the Dome model (QNP-6230RH), and feature a more compact design compared to traditional PTZ cameras. This streamlined and lightweight design greatly eases the installation process. Additionally, the lighter camera head increases the Pan/Tilt speed. The Q series PTZ cameras are equipped with advanced PTZ control for precise and delicate operations. Unlike conventional PTZ cameras, which struggled with accurately tracking moving objects due to preset centered movement, the new Q series offers enhanced stability and accuracy in object tracking, especially when manual control is required.

Camera
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66

Display & Graphics
Color SupportedColor
Maximum Video Resolution1920 x 1080

Environmental Conditions
Maximum Operating Temperature131°F
Minimum Operating Temperature-58°F
Operating Humidity

Exposure
Longest Shutter Speed2 Second
Minimum Illumination0.005 lux
Shortest Shutter Speed1/12,000 Second

General Information
Brand NameHanwha Vision
ManufacturerHanwha Vision
Manufacturer Part NumberQNP-6250
Product ModelQNP-6250
Product Name2MP 25x PTZ
Product SeriesQ
Product TypePTZ Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length4.44-111 mm
Lens IncludedYes
Maximum Focal Length4.44 mm
Minimum Aperturef/3.9

Miscellaneous
Features2MP Resolution, 4.44-111mm (25x) lens, Day and Night (ICR), WDR, DIS (Built-in gyro sensor), H.264, H.265, MJPEG codec, WiseStreamII, Intelligent Analytics, Micro SD/SDHC/SDXC 1slot 256GB

Network & Communication
Remote ManagementYes

Others
ADI Part Number ReplacesSQ-QNP6230
Model Number ReplacesQNP-6230

Physical Characteristics
ColorWhite
Color FamilyWhite
DurabilityDustproof, Waterproof
Form FactorPTZ
Product ColorWhite
Weight (Approximate)3.75 lb

Product Information
Diameter5.98"

Storage
Recording FormatsFull HD
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution2MP
Field of ViewH: 64.66°-2.99°, V: 38.08°-1.68°
HD RecordingYes
Lens TypeVarifocal
Maximum ApertureF1.6
Maximum Frame Rate60 fps
Minimum Focal Length4.44 mm
Optical Zoom25x
