Description
The SBP-UDR serves as a versatile DIN-Rail mount adapter kit, engineered to accommodate a variety of modules on a standard 35mm DIN-Rail channel. This DIN-Rail mounting technique is prevalent in the industrial control and intelligent transportation systems (ITS) sectors, facilitating the installation of electronic and electrical hardware within equipment enclosures. It offers easy installation, enhanced mounting density, and improved organization in confined spaces. For integrating shelf-mounted products onto an existing DIN-Rail, the SBP-UDR acts as a universal solution, occupying minimal additional space thanks to its innovative mounting system. The module is secured to the SBP-UDR adapter using the provided hardware. The aluminum block features multiple sets of no. 6-32 drilled and tapped fixing holes, enabling vertical axis configuration for versatile module placement. The entire setup is then directly clipped onto a standard 35mm DIN-Rail.
