Description

**High-Performance Surveillance Camera**

This advanced surveillance camera delivers crystal-clear imagery around the clock, excelling even in nighttime or low-light environments. Its superior starlight sensitivity allows operation with minimal ambient illumination, while high dynamic range technology ensures detailed visuals in complex lighting scenarios. Available in both 1080p and 720p resolutions, the camera captures up to 60 frames per second, with a variety of premium lenses available for enhanced image clarity.

**Features**

**Superior Low-Light Capabilities**
Leveraging cutting-edge sensor technology and advanced noise suppression, the camera offers outstanding color sensitivity in low-light conditions, maintaining excellent color performance with minimal ambient light.

**Optimal Fast Motion Recording**
The 60 frames per second capability enables optimal recording during fast-moving scenes, ensuring no critical information is lost.

**High Dynamic Range (HDR)**
The HDR feature utilizes a multi-exposure process to capture intricate details in both bright and dark areas of the scene. It facilitates easy recognition of subjects and features, such as faces, even with intense backlighting. The dynamic range is precisely assessed using Opto-Electronic Conversion Function (OECF) analysis in compliance with IEC 62676 Part 5 standards, allowing for reliable camera comparison.

**Advanced Video Analytics**
Incorporating sophisticated video analytics technology, the camera enhances the Intelligence-at-the-Edge approach with powerful functionality. Ideal for controlled settings with limited detection ranges, it reliably identifies, tracks, and analyzes objects, triggering alerts for predefined events. A robust set of alarm rules simplifies complex monitoring tasks and minimizes false positives. Metadata enhances video retrieval efficiency, supports forensic verification, and optimizes business operations, such as people counting or crowd density analysis. Calibration is simplified—input the camera’s height, and the internal gyro/accelerometer sensor completes the precise alignment of video analytics functionality.

**Adaptive Exposure Control**
Intelligent Auto Exposure adjusts automatically to fluctuations in lighting conditions, providing exceptional front light and backlight compensation for perfect imaging in every environment.

Camera
Wide Dynamic RangeYes

Certifications
NDAA CompliantYes
TAA CompliantYes

Display & Graphics
Color SupportedColor, Monochrome
Maximum Video Resolution1920 x 1080

Environmental Conditions
Maximum Operating Temperature131°F
Minimum Operating Temperature-4°F
Operating Humidity100%

Exposure
Longest Shutter Speed1/30 Second
Shortest Shutter Speed1/15000 Second

General Information
Brand NameBosch
ManufacturerBosch
Manufacturer Part NumberNBN-63023-B
Product LineDINION IP
Product ModelNBN-63023MP-B
Product NameFixed camera2 mPMP HDR
Product Series6000
Product TypeIP Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Lens IncludedNo

Miscellaneous
Environmental CertificationChina RoHS, WEEE
Environmentally FriendlyYes
FeaturesAudio Detection, Auto Gain Control, Automatic Defog, Automatic White Balance, Back Light Compensation (BLC), Cross Line Detection, Day/Night, Dynamic Noise Reduction, Enter/Exit Detector, ePTZ, Privacy Masking, Region of Interest, SD Card Local Storage, Tamper Detection, Wide Dynamic Range
Indoor/OutdoorIndoor
Package Contents1C/CS Mount adapter ring for mounting a lens with a C-Mount, 1Data/Alarm connector (12Pins), 1DINION camera, 1Identification label sheet, 1Installation Guide, 1Power connector (2Pins), 1Sensor protection cap (Mount on camera)

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorGray
Color FamilyGray
Form FactorBox Mount
Height2.6"
Product ColorGray
Weight (Approximate)1-52 lb
Width3.1"

Power Description
Input Voltage12V DC, 24V AC

Product Information
Length5.5"
Mount TypeBracket Mount, Ceiling Mount, Junction Box Mount, Pole Mount, Tripod Mount, Wall Mount

Storage
Recording FormatsFull HD
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution2MP
HD RecordingYes
Lens Mount TypeCS Mount
Maximum Frame Rate60fps
Video Signal FormatNTSC, PAL

Video
Analog Video Signal FormatCVBS
