Hanwha ANO-L6022R A-Series 2MP Bullet Camera, 4mm Lens, White

Name: Hanwha ANO-L6022R A-Series 2MP Bullet Camera, 4mm Lens, White
Brand: Hanwha Vision
SKU: ANO-L6022R
Availability: InStock

in stock

In Stock

$68.39

Below is a comprehensive overview of the camera's technical specifications, enriched with industry-relevant terminology:

- Delivers high-definition 2MP (1920 x 1080) resolution for superior image clarity.
- Equipped with a 4mm lens, offering an impressive 84.3° Horizontal Field of View (HFoV).
- Capable of capturing video at 30 frames per second (fps) across all resolutions, utilizing both H.265 and H.264 compression standards.
- Supports H.265, H.264, and MJPEG codecs with the capability for multiple streaming options.
- Features Day & Night functionality with Infrared Cutfilter Removal (ICR) and Wide Dynamic Range (WDR) at 120dB for enhanced low-light performance.
- Advanced detection features including Defocus, Directional, Motion, Enter/Exit, and Tampering detection.
- Includes a Micro SD/SDHC memory slot supporting up to 32GB storage, with Power over Ethernet (PoE) capability for streamlined installation.
- Incorporates innovative Hallway View and WiseStream II technology for optimized bandwidth and storage efficiency.
- Infrared (IR) illumination extends viewable distance up to 30 meters.
- Built to withstand harsh environments with IP66 weather-resistant rating.

SKU: ANO-L6022R Categories: Bullet Cameras, IP Cameras, Video Surveillance Brand: Hanwha Vision

Description

4mm fixed lens outdoor bullet surveillance camera, offering 2MP resolution at 30fps, double codec H.264/MJPEG, equipped with WiseStream II technology, 120dB Wide Dynamic Range (WDR), infrared LEDs with a range of 98 feet, motion detection, tampering alerts, hallway view feature, supports SD card storage up to 32GB, IP66 weatherproof rating, IK10 vandal resistance, and Power over Ethernet (PoE) support.

Camera
Night Vision Distance	98.43 ft
Wide Dynamic Range	Yes

Certifications
Ingress Protection Rating	IP66

Display & Graphics
Color Supported	Color
Maximum Video Resolution	1920 x 1080

Environmental Conditions
Maximum Operating Temperature	131°F
Minimum Operating Temperature	-22°F
Operating Humidity

Exposure
Longest Shutter Speed	2 Second
Shortest Shutter Speed	1/12,000 Second

General Information
Brand Name	Hanwha Vision
Manufacturer	Hanwha Vision
Manufacturer Part Number	ANO-L6022R
Product Model	ANO-L6022R
Product Name	2MP IR Bullet Camera
Product Series	A
Product Type	Bullet Camera

Interfaces/Ports
Network (RJ-45)	Yes

Lens
Focal Length	4 mm
Lens Included	Yes
Maximum Focal Length	4 mm

Miscellaneous
Features	2 MP (1920 x 1080) resolution, 30fps at all resolutions (H.265/H.264), 4mm lens w/ 84.3° HFoV, Day and Night (ICR), WDR (120dB), Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, H.265/H.264, MJPEG codec supported, Multiple streaming, Hallway View, WiseStream II support, IR viewable length 30m, Micro SD/SDHC memory slot (Max. 32GB), PoE, support
Impact Protection Rating	IK10
Indoor/Outdoor	Outdoor

Network & Communication
Remote Management	Yes

Physical Characteristics
Color	White
Color Family	White
Durability	Dustproof, Impact Resistant, Waterproof
Form Factor	Bullet
Product Color	White
Weight (Approximate)	0.86 lb

Product Information
Diameter	3.07"
Mount Type	Backbox Mount, Corner Mount

Storage
Recording Formats	Full HD
Storage Type	Memory Card

Technical Information
Connectivity Technology	Wired
Effective Camera Resolution	2MP
Field of View	H: 84.3°, V: 45.6°, D: 98.3°
HD Recording	Yes
Lens Type	Fixed Focus
Maximum Aperture	F2.0
Maximum Frame Rate	30 fps
Minimum Focal Length	4 mm
Night Vision	Yes
Night Vision Type	Infrared
