Description

The relentless pace of urban environments results in a continuous flow of pedestrians and vehicles maneuvering through city streets at all hours. As cities expand, so does the network of surveillance cameras, often overwhelming operators with an overflow of data, given that traditional camera systems with motion detection tend to trigger an excessive number of event alarms. This can put significant pressure on operators who must verify each alert, potentially causing delays in response times. AI-enhanced P series AI cameras offer a substantial boost to operator efficiency. These advanced cameras incorporate the BestShot feature, which ensures that only the most relevant images of classified objects are transmitted to the backend server. They support full video imaging up to 4K resolution, capturing detailed object features and tagged attributes metadata. Users can choose to stream full video at less than 4K resolution or optimize bandwidth and storage with the BestShot feature.

Camera
Night Vision Distance98.43 ft
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66, IP67
NDAA CompliantYes
TAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution3840 x 2160

Environmental Conditions
Maximum Operating Temperature131°F
Minimum Operating Temperature-40°F
Operating Humidity

Exposure
Longest Shutter Speed1/5 Second
Minimum Illumination0.005 lux
Shortest Shutter Speed1/12,000 Second

General Information
Brand NameHanwha Vision
ManufacturerHanwha Vision
Manufacturer Part NumberPNO-A9081R
Product ModelPNO-A9081R
Product Name4K AI IR Bullet Camera
Product SeriesP
Product TypeBullet Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length4.5-10 mm
Lens IncludedYes
Maximum Focal Length10 mm
Minimum Aperturef/2.65

Miscellaneous
Features0.05Lux at F1.6 (Color), 0 Lux (B/W IR LED On), 30fps at all resolutions (H.265/H.264), 30m (98ft) IR illumination, 4.5-10mm (2.2x) motorized varifocal lens, 4K/8 MP (3840 x 2160) resolution, Day and Night (ICR), WDR (120dB), P-Iris, Digital image stabilization with built-in Gyro sensor, H.265, H.264, MJPEG codec supported, multiple streaming, Object detection and classification (Person, Face, Vehicle, License Plate), Attribute, BestShot, Video Analytics based on AI
Impact Protection RatingIK10
Indoor/OutdoorOutdoor

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorGray
Color FamilyWhite
DurabilityDustproof, Impact Resistant, Vandal Resistant, Waterproof
Form FactorBullet
Height14.5"
Product ColorWhite
Weight (Approximate)5.47 lb
Width3.6"

Power Description
Input Voltage12V DC

Product Information
Diameter3.58"
Length14.5"
Mount TypePole Mount

Storage
Recording Formats4K
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution8MP
Field of ViewH: 101.4°-45.5°, V: 53.6°-25.5°, D: 120.7°-52.3°
HD RecordingYes
Lens TypeVarifocal
Maximum ApertureF1.6
Maximum Frame Rate30 fps
Minimum Focal Length4.5 mm
Night VisionYes
Night Vision TypeInfrared
Optical Zoom2.2x

Video
Analog Video Signal FormatCVBS

Warranty
Limited Warranty3 Year
