Description

This budget-friendly, compact mini dome camera delivers exceptional image quality, even in challenging lighting scenarios. With its integrated deep learning processing unit, it enables sophisticated edge-based analytics.

Exceptional Image Quality

This mini dome camera provides outstanding 4 MP image clarity in tough lighting conditions. Featuring Wide Dynamic Range (WDR), it ensures sharp details in scenes with both high and low light areas. The Lightfinder technology ensures vibrant color images even in low light environments. Additionally, it offers a broad 130° field of view and is factory-focused to eliminate the need for manual adjustment.

Advanced Analytics Capabilities

This mini dome camera supports intelligent analytics powered by on-edge deep learning technology. This allows it to generate valuable metadata for rapid forensic searches in both live and recorded video footage. Preinstalled object analytics enables targeted detection and monitoring, tailored to specific requirements. With ACAP support, the system can be enriched with custom applications. The compact camera also offers the ability to integrate audio or I/O connectivity via accessories.

Compact and Cost-Effective Design

This cost-effective mini dome camera is compatible with a variety of mounting accessories for flexible and discreet installation. The bayonet-fitted casing allows for quick and easy installation. The design is both compact and vandal-resistant, protecting against redirection, defocusing, dust, and water. Equipped with Axis Zipstream technology supporting H.264/H.265, it reduces bandwidth and storage demands. Edge storage capability allows direct recording to an onboard memory card, while Axis Edge Vault safeguards device identity and simplifies the authorization of devices within your network infrastructure.

Camera
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP42
TAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution2688 x 1512

Environmental Conditions
Maximum Operating Temperature113°F (45°C)
Minimum Operating Temperature32°F (0°C)
Operating Humidity85%

Exposure
Longest Shutter Speed1/5 Second
Shortest Shutter Speed1/38500 Second

General Information
Brand NameAxis Communications
ManufacturerAxis Communications
Manufacturer Part Number02374-001
Product LineM
Product ModelM3086-V
Product NameM3086-V Dome Camera
Product SeriesM30
Product TypeNetwork Camera

Interfaces/Ports
HDMIYes
Network (RJ-45)Yes

Lens
Focal Length2.4 mm
Lens IncludedYes
Maximum Focal Length2.40 mm

Miscellaneous
FeaturesBuilt-in Microphone, Cross Line Detection, Day/Night, HTTPS Encryption, Human Detection, Multi-view Stream, Password Protection, Removable IR Cut-off Filter, Vehicle Detection, Wide Dynamic Range
Impact Protection RatingIK08
Indoor/OutdoorIndoor

Network & Communication
Remote ManagementYes

Others
ADI Part Number ReplacesZ4-01708001
Model Number Replaces01708-001M3066-V

Physical Characteristics
ColorWhite
Color FamilyWhite
DurabilityDust Resistant, Impact Resistant, Vandal Resistant, Water Resistant
Form FactorMini Dome
Height2.2"
Product ColorWhite
Weight (Approximate)5.29 oz

Product Information
Diameter4"
Mount TypeCeiling Mount, Wall Mount

Storage
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution4MP
Field of ViewHorizontal field of view: 130° Vertical field of view: 93°
HD RecordingYes
Lens TypeFixed
Maximum Aperturef/2.1
Maximum Frame Rate30 fps
Minimum Focal Length2.4 mm
