Description

Utilizing cutting-edge H.265 encoding technology, the Dahua corner network camera offers superior compression efficiency, significantly conserving bandwidth and storage capacity. This camera integrates starlight imaging, intelligent infrared technology, and advanced video analytics while featuring robust waterproof, dustproof, and vandal-resistant capabilities, meeting IP67 and IK10+50J standards.

**Key Features**

**Smart Encoding Solutions (H.265+ & H.264+)**
Using an innovative scene-adaptive rate control algorithm, the smart encoding technology enhances compression efficiency beyond traditional H.265 and H.264 protocols, delivering high-quality video while minimizing storage and transmission costs.

**Starlight Technology**
Designed for low-light conditions, Dahua’s Starlight technology provides vivid, colorful video even in extremely dim environments, ensuring excellent image quality regardless of lighting challenges.

**Perimeter Protection**
Equipped with deep learning algorithms, the perimeter protection technology accurately identifies humans and vehicles. By discerning target types such as tripwire, intrusion, rapid movement, parking, loitering, and gathering, it significantly reduces false alarms in restricted zones.

**Distortion Correction**
The advanced distortion correction algorithm effectively aligns horizontal and vertical image distortions to mirror real-world scenarios accurately.

**Invisible IR LED Illuminator (940 nm)**
Featuring a 940 nm IR LED, the camera’s LED illuminator remains invisible to the naked eye, enhancing discreet operation.

**Protection and Resilience (IP67, IK10, Wide Voltage Range)**
– **IP67:** The camera endures rigorous dust and immersion tests, maintaining dustproof integrity and operational capability after 30 minutes in 1-meter deep water.
– **IK10:** The casing withstands severe vandalism tests, withstanding impacts of up to 50J impact energy.
– **Wide Voltage Tolerance:** Capable of handling a ±30% input voltage variation, the camera is particularly suited for outdoor environments with fluctuating power supplies.

Camera
Image Sensor TypeCMOS
Night Vision Distance32.81 ft
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP67

Display & Graphics
Color SupportedColor
Maximum Video Resolution2688 x 1520

Environmental Conditions
Maximum Operating Temperature140°F (60°C)
Minimum Operating Temperature-40°F (-40°C)
Operating Humidity95%

Exposure
Longest Shutter Speed1/3 Second
Shortest Shutter Speed1/100000 Second

General Information
Brand NameDahua
ManufacturerZhejiang Dahua Technology Co., Ltd.
Manufacturer Part NumberDH-IPC-HCBW8442N
Product LineWizMind
Product ModelDH-IPC-HCBW8442N
Product Name4MP WDR IR Corner Network Camera
Product SeriesPro
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length2.5 mm
Lens IncludedYes
Maximum Focal Length2.50 mm

Miscellaneous
Country of OriginCN
FeaturesAuto Gain Control, Automatic White Balance, Built-in Microphone, Day/Night, Motion Detection, Privacy Masking, SD Card Local Storage
Impact Protection RatingIK10
Indoor/OutdoorOutdoor

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorWhite
Color FamilyWhite
DurabilityDustproof, Impact Resistant, Vandal Resistant, Waterproof
Form FactorDome
Height4.1"
Product ColorWhite
Weight (Approximate)3.01 lb
Width8.3"

Power Description
Input Voltage12V DC

Product Information
Length8.2"
Mount TypeCorner Mount

Storage
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution4MP
Field of ViewHorizontal: 135° Vertical: 90°
HD RecordingYes
Lens Mount TypeM12 Mount
Lens TypeFixed
Maximum Aperturef/2
Maximum Frame Rate30 fps
Minimum Focal Length2.5 mm
Night VisionYes
Night Vision TypeInfrared
Number of IR LEDs2
Video FormatsH.264, H.265, MJPEG
Video Signal FormatNTSC

Warranty
Limited Warranty5 Year
