Description

Leveraging advanced deep learning algorithms, Hikvision’s AcuSense technology enhances security systems with precise classification alarms for human and vehicle targets on both front-end and back-end devices, significantly boosting alarm efficiency and effectiveness.

– Captures high-quality images with 4 MP resolution
– Features clear imaging even in strong backlight conditions thanks to 120 dB WDR technology
– Utilizes efficient H.265+ compression technology
– Includes a built-in microphone for real-time audio surveillance
– Offers water and dust resistance (IP67) and vandal resistance (IK10)
– Specializes in human and vehicle target classification enabled by deep learning

Camera
Night Vision Distance98.43 ft
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP67
TAA CompliantNo

Display & Graphics
Color SupportedColor
Maximum Video Resolution2688 x 1520

Environmental Conditions
Maximum Operating Temperature140°F (60°C)
Minimum Operating Temperature-22°F (-30°C)
Operating Humidity95%

Exposure
Longest Shutter Speed1/3 Second
Shortest Shutter Speed1/100000 Second

General Information
Brand NameHikvision
ManufacturerHikvision
Manufacturer Part NumberDS-2CD2143G2-IU 2.8MM(BLACK)
Product LineValue
Product ModelDS-2CD2143G2-IU
Product Name4 MP AcuSense Fixed Dome Network Camera
Product SeriesPro, Value
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length2.8 mm
Lens IncludedYes
Maximum Focal Length2.8 mm

Miscellaneous
Environmental CertificationREACH, RoHS, WEEE
Environmentally FriendlyYes
Features3D Digital Noise Reduction, Back Light Compensation (BLC), Cross Line Detection, Day/Night, Face Detection, Highlight Compensation (HLC), Motion Detection, SD Card Local Storage, Tampering Alarm
Impact Protection RatingIK10
Indoor/OutdoorOutdoor

Network & Communication
Remote ManagementYes

Others
ADI Part Number ReplacesHX-OD2143F2B, HX-OD2143F4B, HX-OD2183F2B
Model Number ReplacesDS-2CD2143G0-IB 2.8MMDS-2CD2143G0-IB(4MM), DS-2CD2183G0-IB 2.8MM

Physical Characteristics
ColorBlack
Color FamilyBlack
DurabilityDust Resistant, Impact Resistant, Vandal Resistant, Waterproof
Form FactorDome
Product ColorBlack
Weight (Approximate)1.26 lb

Power Description
Input Voltage12V DC

Product Information
Diameter4.8"
Mount TypeCeiling Mount, Corner Mount, Junction Box Mount, Pendant Mount, Pole Mount, Vertical Mount, Wall Mount

Storage
Recording FormatsHD
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution4MP
Field of Viewhorizontal FOV 103°, vertical FOV 55°, diagonal FOV 122°
HD RecordingYes
Lens Mount TypeM12
Lens TypeFixed
Maximum Aperturef/1.6
Maximum Frame Rate30 fps
Minimum Focal Length2.8 mm
Night VisionYes
Night Vision TypeInfrared

Warranty
Limited Warranty36 Month
