Description

### Line Crossing Detection
When a specified line is crossed from any direction, a notification is generated to alert of the event.

### Perimeter Intrusion Detection
Setting a designated area boundary allows for detection of movement towards, away from, or across the area, triggering an alarm for unauthorized access.

### Video Tampering Detection – Color Anomaly
Any alteration in the camera’s color accuracy will prompt an event notification, identifying potential tampering.

### Video Tampering Detection – Scene Change
If the camera is repositioned, resulting in a new Field of View (FoV), a notification is sent to indicate a possible scene tampering.

### Video Tampering Detection – Video Blur
Emergency notifications will be triggered when a significant blur or loss in image clarity is detected, marking it as potential interference.

### Smart IR™ Technology
This feature automatically calibrates infrared illumination to prevent overexposure in close-up objects, ensuring clear black-and-white imaging with retained detail.

### True Wide Dynamic Range (WDR)
Utilizing advanced sensors, cameras with True WDR technology efficiently manage diverse lighting conditions, balancing dark and bright areas within the same shot.

### H.265 Video Codec Support
This advanced High-Efficiency Video Coding standard provides 25% to 50% superior data compression rates, preserving video quality while optimizing storage efficiency.

Camera
Night Vision Distance164 ft
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP67
NDAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution2560 x 1440

Environmental Conditions
Maximum Operating Temperature140°F (60°C)
Minimum Operating Temperature-22°F (-30°C)
Operating Humidity95%

Exposure
Longest Shutter Speed1/2 Second
Shortest Shutter Speed1/100000 Second

General Information
Brand NameDigital Watchdog
ManufacturerDigital Watchdog
Manufacturer Part NumberDWC-VSDG04MI
Product LineMEGApix
Product ModelDWC-VSDG04MI
Product NameMEGApix 4MP vandal dome IP camera with a vari-focal lens and IR
Product SeriesV-Class
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length2.8-12 mm
Lens IncludedYes
Maximum Focal Length12 mm

Miscellaneous
Environmental CertificationRoHS
Environmentally FriendlyYes
Features3D Digital Noise Reduction, Auto Gain Control, Back Light Compensation (BLC), Cross Line Detection, Day/Night, Highlight Compensation (HLC), Human Detection, Noise Reduction, Smart IR, Tamper Detection, Tampering Alarm, White Balance
Impact Protection RatingIK10

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorWhite
Color FamilyWhite
DurabilityDustproof, Impact Resistant, Vandal Resistant, Waterproof, Weather Resistant
Form FactorVandal Dome
Product ColorWhite
Weight (Approximate)1.94 lb

Power Description
Input Voltage12V DC

Product Information
Mount TypeCeiling Mount, Junction Box Mount, Wall Mount

Storage
Recording Formats2K
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution4MP
Field of ViewHorizontal Field of View (HFOV) 92°~31°
HD RecordingYes
Lens TypeVarifocal
Maximum Aperturef/1.4
Maximum Frame Rate30 fps
Minimum Focal Length2.80 mm
Night VisionYes
Night Vision TypeInfrared
Optical Zoom4.3x

Warranty
Limited Warranty5 Year
