Description

The Sarix Corner Camera3 Series is a robust fixed IP camera solution designed for comprehensive video surveillance in small to medium-sized areas. With an IK10+ 50-joule impact rating and durable steel construction, this camera is perfect for environments prone to tampering or vandalism.

  • Wide field of view with fixed lens
  • Supports H.264 and H.265 codecs with Pelco Smart Compression and SureVision technology
  • Equipped with advanced Smart Analytics powered by Motorola Solutions
  • Vandal-resistant IK10+ impact rating
  • IP66 and IP67 rated for water and dust resistance
  • Efficiently reduces bandwidth and storage requirements
  • Backed by a five-year warranty with comprehensive service and support
  • Operates efficiently in temperatures from -40°C to 55°C
  • Compliant with ONVIF Profile S, G, and T standards
  • Features built-in microphone for audio recording
  • Excels in capturing details in high contrast lighting conditions
Camera
Night Vision Distance49.21 ft
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66, IP67

Display & Graphics
Color SupportedColor, Monochrome
Maximum Video Resolution2592 x 1944

Environmental Conditions
Maximum Operating Temperature131°F (55°C)
Minimum Operating Temperature-40°F (-40°C)
Operating Humidity95%

Exposure
Longest Shutter Speed1/7 Second
Shortest Shutter Speed1/8196 Second

General Information
Brand NamePelco by Motorola Solutions
ManufacturerSchneider Electric SA
Manufacturer Part NumberIBD532-1
Product LineSarix
Product ModelIBD532-1
Product NameSarix Corner Mount Camera 3 Series
Product Series3
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length2.3 mm
Lens IncludedYes
Maximum Focal Length2.3 mm

Miscellaneous
Environmental CertificationREACH, RoHS
Environmentally FriendlyYes
Features3D Noise Reduction, Audio Compression, Automatic White Balance, Back Light Compensation (BLC), Built-in Microphone, Day/Night, Motion Detection, Multi-view Stream, White Balance, Wide Dynamic Range
Impact Protection RatingIK10
Indoor/OutdoorIndoor

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorWhite
Color FamilySilver
DurabilityDustproof, Impact Resistant, Vandal Resistant, Waterproof
Form FactorDome
Height4.8"
Product ColorSilver
Weight (Approximate)7.08 lb
Width6.4"

Power Description
Input Voltage12V DC, 24V AC

Product Information
Length6.4"
Mount TypeCorner Mount

Storage
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution5MP
Field of View135° 133° 95° 74°
HD RecordingYes
Lens TypeFixed
Maximum Aperturef/2.2
Maximum Frame Rate30 fps
Minimum Focal Length2.3 mm
Night VisionYes
Night Vision TypeInfrared

Warranty
Limited Warranty5 Year
