Description

The Illustra Flex Gen 4 Mini-Domes exemplify the advancements in edge-based intelligence. With cutting-edge AI-driven object classification, these cameras can distinguish between different categories such as person, car, bus, motorcycle, and more.

Enhanced forensic search capabilities and automated situational awareness reduce the likelihood of missed incidents and false alarms. Users can select from a comprehensive set of analytic rules to tailor the surveillance solution to their specific needs, enabling immediate access to transformative data.

Engineered to deliver exceptional image quality, the robust Illustra Flex Mini-Domes provide a feature-rich surveillance solution suitable for diverse applications.

Camera
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66, IP67
TAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution3840 x 2160

Environmental Conditions
Maximum Operating Temperature140°F (60°C)
Minimum Operating Temperature14°F (-10°C)

General Information
Brand NameAmerican Dynamics
ManufacturerJohnson Controls
Manufacturer Part NumberIFS08D13ITA4
Product LineFlex
Product ModelIFS08-D13-ITA4
Product NameFlex Gen4 IFS08-D13-ITA4 Network Camera
Product SeriesGen4
Product TypeNetwork Camera

Interfaces/Ports
HDMIYes
Network (RJ-45)Yes

Lens
Focal Length3.6-11 mm
Lens IncludedYes
Maximum Focal Length11 mm
Minimum Aperturef/1.5

Miscellaneous
Environmental CertificationRoHS, WEEE
Environmentally FriendlyYes
FeaturesAI Analytics, Alarm Detection, Day/Night, Defog, Human Detection, Motion Detection, Privacy Masking, Tamper Detection, Vehicle Detection, Wide Dynamic Range
Impact Protection RatingIK10
Indoor/OutdoorIndoor
Package Contents1 x Flex Gen 4 Dome Camera1 x Torx T10 Security L-Key1 x Adaptor Plate (for use with pendant cap and electrical box)3 x 18mm screws & 3 x Plastic screw anchorsand more below, 1 x Desiccant bag, 1 x Mounting template sticker, 1 x Plastic side cover, 1 x Printed Regulatory Document & 1 x Printed QSG, 1 x Waterproof cap, 1 x Waterproof rubber insert, 2 x 8 mm screws (for use with the pendant cap)

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorWhite
Color FamilyWhite
DurabilityDustproof, Impact Resistant, Vandal Resistant, Waterproof
Form FactorMini Dome
Height4.2"
Weight (Approximate)2.14 lb

Power Description
Input Voltage24V AC, 24V DC

Product Information
Diameter4.8"
Mount TypeCeiling Mount, Corner Mount, Gooseneck Mount, Pendant Mount, Pole Mount, Recessed Mount, Wall Mount

Storage
Recording Formats4K
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution8MP
Field of ViewHorizontal: 95°, Vertical: 53°
HD RecordingYes
Lens TypeVarifocal
Maximum Aperturef/2.8
Maximum Frame Rate15 fps
Minimum Focal Length3.60 mm
Optical Zoom3x

Warranty
Limited Warranty5 Year
