Description

The Pro Compact Mini-Dome IP Cameras deliver high-definition surveillance with 2MP and 3MP resolutions, perfect for industries such as retail, commercial real estate, healthcare, and banking where discreet security is paramount. With an IP66/67 and IK10 rating, these cameras are engineered to withstand challenging weather conditions and resist vandalism. Their True Wide Dynamic Range up to 120dB ensures superior video quality in demanding lighting environments. Optimize installation and operational efficiency by integrating these cameras with a network video recorder (NVR) solution at no additional licensing cost.

**Optimal Surveillance with Corridor Mode**

These compact security cameras provide versatile viewing options, including a corridor mode. The corridor mode offers a 9×16 aspect ratio, which is ideal for vertically oriented settings such as narrow hallways, alleys, grocery aisles, or any area that benefits from a portrait layout rather than a landscape view.

**Advanced Bandwidth Efficiency**

The Illustra IntelliZip technology enhances bandwidth management beyond traditional H.264 and H.265 standards, significantly reducing network and storage demands. This innovative feature dynamically adjusts streaming parameters, improving video quality during motion detection while optimizing bitrate for less active scenes.

**Reliable Failover with TrickleStor**

The Pro Compact Mini-Dome product line features the TrickleStor capability, ensuring continuous video recording even during network interruptions. If connectivity between the NVR and cameras is lost, recording switches automatically to the camera’s SD card. Once restored, the video is seamlessly transferred back to the NVR for uninterrupted playback.

**Robust Cybersecurity Measures**

Adhering to stringent cybersecurity protocols, these mini-domes are part of a comprehensive Cyber Protection Product Security Program. This initiative encompasses secure design, rigorous development processes, and proactive incident response, ensuring resilience in the evolving cybersecurity landscape.

Camera
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP67
NDAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution2048 x 1536

General Information
Brand NameAmerican Dynamics
ManufacturerJohnson Controls
Manufacturer Part NumberIPS03CFOCWST
Product LinePro
Product ModelIPS03CFOCWST
Product NamePro IPS03CFOCWST Network Camera
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length2.8 mm
Maximum Focal Length2.8 mm

Miscellaneous
Environmental CertificationRoHS, WEEE
Environmentally FriendlyYes
Impact Protection RatingIK10
Indoor/OutdoorOutdoor

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorWhite
DurabilityDustproof, Impact Resistant, Waterproof
Form FactorMini Dome
Height2"
Weight (Approximate)1.10 lb
Width4.3"

Product Information
Mount TypeCorner Mount, Pendant Mount, Pole Mount, Recessed Mount

Storage
Recording FormatsHD

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution3MP
HD RecordingYes
Lens TypeFixed
Maximum Frame Rate30 fps
Minimum Focal Length2.8 mm
