Description

The FLEXIDOME corner 7100i IR is a state-of-the-art, vandal-resistant corner mount camera, engineered with an anti-ligature, no-grip design. This surveillance solution offers a comprehensive and detailed view of any space without blind spots, while the smart invisible IR ensures consistent image quality in complete darkness or low-light conditions. Ideal for 24/7 surveillance in high-risk, vandal-prone environments, the camera boasts an IK10+ 50J rating for superior resistance against vandalism. Its extensive inputs and outputs, including Alarm and Audio capabilities, enhance its functionality for more interactive security systems. Integrated AI-based Intelligent Video Analytics provides complete situational awareness, triggering pertinent alerts to ensure safety and peace of mind in highly dangerous and stressful settings. Additionally, its Intelligent Audio Analytics interprets captured sounds, distinguishing between a gunshot and random loud noises, thereby elevating the effectiveness of security measures.

Camera
Night Vision Distance49.21 ft
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66

Display & Graphics
Color SupportedColor, Monochrome
Maximum Video Resolution2816 x 2112

Environmental Conditions
Maximum Operating Temperature122°F (50°C)
Minimum Operating Temperature14°F (-10°C)
Operating Humidity93%

Exposure
Shortest Shutter Speed1/30000 Second

General Information
Brand NameBosch
ManufacturerThe Bosch Group
Manufacturer Part NumberNCE7703FK
Product LineFLEXIDOME corner
Product ModelNCE-7703-FK
Product NameFLEXIDOME corner 7100i NCE-7703-FK Network Camera
Product Series7100i
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length2.5 mm
Lens IncludedYes
Maximum Focal Length2.50 mm

Miscellaneous
Environmental CertificationEU RoHS, EU WEEE
Environmentally FriendlyYes
FeaturesBack Light Compensation (BLC), Built-in IR LED, Built-in Microphone, Day/Night, Human Detection, Privacy Masking, Vehicle Detection, Video Content Analytics, White Balance
Impact Protection RatingIK10, IK11
Indoor/OutdoorIndoor, Outdoor
Package Contents1 FLEXIDOME corner 7100i IR camera1 Corner mount box1 Face plate1 IR cover1 TR20 Allen key for camera installation1 RJ-45 punch-through aidand more below, 1 Quick Installation Guide, 1 Safety and security information manual, 2 M20 rubber grommets (attached to the camera), 3 MAC address labels

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorWhite
Depth8"
DurabilityDustproof, Impact Resistant, Vandal Resistant, Waterproof
Form FactorDome
Height5.4"
Weight (Approximate)4.19 lb
Width7.3"

Power Description
Input Voltage12V DC, 24V AC

Product Information
Mount TypeCorner Mount

Storage
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution6MP
Field of ViewHorizontal: 131°, Vertical: 96°
HD RecordingYes
Lens TypeFixed
Maximum Aperturef/2.4
Maximum Frame Rate30 fps
Minimum Focal Length2.5 mm
Night VisionYes
Night Vision TypeInfrared
