Description

  • H.265, H.264 Main and High profiles, MJPEG video compression
  • Supports up to 5 megapixel (MP) resolution
  • Captures up to 60 frames per second (fps) at 4 MP for 5MP models
  • Micro SDHC and SDXC compatible, addressable up to 2TB, 128GB tested
  • Infrared illumination up to 25 meters
  • Operating temperature range from -20°C to 55°C (-4°F to 131°F)
  • Basic video analytics including Motion Detection and Camera Sabotage
  • IEEE802.3af Power over Ethernet (PoE) support
  • Enhanced compression with Smart Technology
  • Vandal resistance rated at IK10
  • IP66/67 rated for ingress protection
  • Compatible with various video management systems
  • ONVIF compliant with Profile S, G, Q, and T
  • Comprehensive 3-year warranty and support

**Professional Surveillance Range**
The Professional Range of surveillance cameras offers robust, versatile, and cost-effective solutions, incorporating the most sought-after features and functionalities. These include a variety of options for indoor and outdoor environments, such as bullet and dome cameras, as well as vandal-resistant wedges and box camera designs. Customize the camera’s performance attributes and form factor to match diverse lighting conditions, settings, and applications.

**Wedge Camera Series**
Within the Professional Range, the Wedge Camera Series offers IR vandal-resistant cameras with fixed lens options, perfect for surveillance in compact spaces. This series also includes advanced color processing and true Wide Dynamic Range (WDR) to enhance visibility in challenging lighting situations. With IK10, IP66/67, and Type 4X certifications, these cameras are built for durability in tough environments.

**Video Capabilities**
Professional Range cameras provide three simultaneous video streams. These streams can be efficiently encoded using H.265, H.264 High or Main profiles, or MJPEG formats. Adjustable frame rates and variable bit rates allow for optimized image quality with bandwidth and storage efficiency. The Smart Compression Technology minimizes storage and bandwidth use in both H.264 and H.265 formats.

**Edge Storage**
Professional Range cameras come with onboard edge storage featuring micro SDHC and SDXC card support. Video segments of varying lengths can be saved to the card in response to alarms, or video can be continuously recorded to the SD card during network disruptions. Retrieval is possible via FTP protocol or any ONVIF Profile G compliant client.

Camera
Night Vision Distance82 ft
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP67
NDAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution1280 x 960

Environmental Conditions
Maximum Operating Temperature131°F (55°C)
Minimum Operating Temperature-4°F (-20°C)
Operating Humidity95%

Exposure
Longest Shutter Speed1 Second
Shortest Shutter Speed1/10000 Second

General Information
Brand NamePelco by Motorola Solutions
ManufacturerMotorola Solutions, Inc.
Manufacturer Part NumberIWP133-1ERS
Product LineSarix
Product ModelIWP133-1ERS
Product NameSarix Professional IWP133-1ERS Network Camera
Product SeriesSarix Professional 3
Product TypeNetwork Camera

Lens
Focal Length2.8 mm
Lens IncludedYes
Maximum Focal Length2.8 mm

Miscellaneous
FeaturesAuto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Day/Night, Digital Noise Reduction, Motion Detection, Wide Dynamic Range
Impact Protection RatingIK10
Indoor/OutdoorOutdoor

Network & Communication
Remote ManagementYes

Others
ADI Part Number ReplacesPE-IJP1211IS
Model Number ReplacesIJP121-1IS

Physical Characteristics
ColorWhite
DurabilityDustproof, Impact Resistant, Vandal Resistant, Waterproof, Weather Resistant
Form FactorWedge
Height2.2"
Weight (Approximate)13.40 oz
Width4.3"

Product Information
Mount TypeSurface Mount

Storage
Recording FormatsHD
Storage TypeMemory Card

Technical Information
Effective Camera Resolution1MP
Field of ViewHorizontal: 112° Vertical: 60° Diagonal: 132°
HD RecordingYes
Lens TypeFixed
Maximum Aperturef/2
Maximum Frame Rate30 fps
Minimum Focal Length2.8 mm
Night VisionYes
Night Vision TypeInfrared

Warranty
Limited Warranty3 Year
