Description

The TNO-6010M is a high-performance network-powered mobile camera specifically designed for in-vehicle applications. It offers exceptional video quality with a 2 MP resolution at 60fps and is equipped with a 2.8mm fixed lens providing a 113.7° field of view. The camera supports H.265, H.264, and MJPEG compression formats, enhanced by WiseStream II technology for efficient bandwidth usage. Built for durability, it boasts 150dB Wide Dynamic Range, High Light Compensation, and is rated IP66, IK10, and NEMA 4X for protection against harsh environments. Key features include advanced video analytics, sound classification, fog detection, and defog capability. Installation is simplified with its USB port, analog video output, and Power over Ethernet (PoE) support. The camera is also equipped with a single SD card slot and is capable of operating in temperatures ranging from -30°C to +55°C (-22°F to +131°F). Its versatile dual-joint design allows for adjustable mounting, making it adaptable to a wide range of vehicles.

Camera
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66
NDAA CompliantYes

Display & Graphics
Color SupportedColor, Monochrome
Maximum Video Resolution1600 x 1200

Environmental Conditions
Maximum Operating Temperature131°F
Minimum Operating Temperature-22°F
Operating Humidity

Exposure
Longest Shutter Speed1/12000 Second
Minimum Illumination0.004 lux
Shortest Shutter Speed2 Second

General Information
Brand NameHanwha Vision
ManufacturerHanwha Vision
Manufacturer Part NumberTNO-6010M
Product ModelTNO-6010M
Product Name2MP Front-Facing Mobile Camera
Product SeriesX
Product TypeMobile Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length2.8 mm
Lens IncludedYes
Maximum Focal Length2.8 mm

Miscellaneous
FeaturesAlarm Triggering, Auto Tracking, Built-in Mechanical ICR, Day/Night, Gain Control, Motion Detection, SD Card Local Storage, Tampering Alarm, White Balance, Wide Dynamic Range
Impact Protection RatingIK10
Indoor/OutdoorIndoor, Outdoor

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorBlack
Color FamilyBlack
DurabilityDustproof, Impact Resistant, Vibration Resistant, Waterproof
Product ColorBlack
Weight (Approximate)2.58 lb

Product Information
Diameter2.4"
Length14.6"
Mount TypeBoard-in Type

Storage
Recording FormatsFull HD
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution2MP
Field of ViewH: 113.7°, V: 61.5°, D: 134.5°
HD RecordingYes
Lens Mount TypeBoard Mount
Lens TypeFixed
Maximum ApertureF2.0
Maximum Frame Rate60 fps
Minimum Focal Length2.8 mm
