Description

The AXIS P3735-PLE surveillance camera provides four channels, each delivering 2MP resolution at 30 frames per second, allowing the capture of both expansive views and zoomed-in, detailed images. It features advanced day/night functionality and 360° infrared illumination with independently controllable LEDs and a removable IR cut filter, ensuring clear, reflection-free imagery and superior image quality even in low light conditions or complete darkness. Additionally, its Forensic Wide Dynamic Range (WDR) allows for excellent clarity in scenes with both dark and light areas. This device supports the streaming of metadata and AXIS Object Analytics across multiple channels, enabling the detection and classification of people and vehicles when they enter predefined zones. This functionality allows for the counting of selected objects within an area of interest and the ability to trigger alarms if specified thresholds are surpassed.

Camera
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66, IP6K9K
TAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution1920 x 1080
Number of Sensors4

Environmental Conditions
Maximum Operating Temperature50 deg C
Minimum Operating Temperature-30 deg C
Operating Humidity100%

Exposure
Longest Shutter Speed1.5 Second
Shortest Shutter Speed1/28000 Second

General Information
Brand NameAxis Communications
Edge EnabledYes
ManufacturerAxis Communications
Manufacturer Part Number02633-001
Product LineP
Product ModelP3735-PLE
Product NameAXIS P3735-PLE Panoramic Camera
Product SeriesP37
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length3.18-8.12 mm
Lens IncludedYes
Maximum Focal Length8.10 mm
Minimum Aperturef/3.2

Miscellaneous
Features360 deg IR illumination with individually controlled LEDs, 4 x 2 MP at 30 fps per channel, Axis Edge Vault safeguards the device, Flexible mounting options, Support for advanced analytics
Impact Protection RatingIK09
Indoor/OutdoorIndoor

Network & Communication
Remote ManagementYes

Others
ADI Part Number ReplacesZ4-02218001
Model Number Replaces02218-001

Physical Characteristics
ColorWhite
Color FamilyWhite
DurabilityDustproof, Impact Resistant, Tamper Resistant, Waterproof
Product ColorWhite
Weight (Approximate)4.41 lb

Storage
Recording FormatsFull HD
Storage TypeMemory Card/Cloud

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution2MP
Field of ViewVarifocal, 3.2-8.1 mm, F1.9-3.2/Horizontal field of view: 108°-40°/Vertical field of view: 55°-23°/Diagonal field of view: 131°-46°
HD RecordingYes
Lens TypeVarifocal
Maximum ApertureF1.9-3.2
Maximum Frame Rate30 fps
Minimum Focal Length3.20 mm
Optical Zoom2.5x
