Description

Delivering comprehensive 180°/360° panoramic surveillance with zero blind spots, this fisheye camera integrates advanced edge analytics powered by deep learning technology. Its ultra-compact design makes it perfect for high-quality indoor security applications.

Superior Video Quality

This 6 MP panoramic camera offers an exceptional field of view with remarkable clarity and detail, eliminating any blind spots. It provides full 360° or 180° panoramic coverage at up to 30 frames per second. Equipped with Lightfinder and Forensic WDR technologies, it captures vivid colors and fine details even in challenging lighting conditions or near darkness. Its stereoscopic lens and digital PTZ capabilities allow users to customize viewing areas and zoom levels in up to four areas simultaneously. Powered by the latest system-on-chip technology, this camera ensures enhanced image processing and superior image quality.

Edge-Based Deep Learning

This indoor fisheye camera features a deep learning processing unit for enhanced processing and storage capabilities at the edge. It enables advanced data collection and analysis directly on the device. It also generates valuable metadata, streamlining forensic searches in both live and recorded footage. With Object Analytics, the camera can accurately detect and classify moving objects, tailored to specific operational requirements. Additionally, support for the latest application platform version allows for the integration of custom applications utilizing deep learning on the edge.

Stylish Design and Easy Installation

This discreet and cost-effective camera is designed for quick and simple installation. Accessory casings are available, allowing it to be repainted to seamlessly blend into any environment. Pre-focused from the factory, it features digital roll functionality for remote adjustment of camera orientation, eliminating the need for manual intervention. Innovative technology reduces bandwidth and storage demands without sacrificing image quality, supporting both H.264 and H.265 formats.

Camera
Wide Dynamic RangeYes

Certifications
TAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution2560 x 1920

Environmental Conditions
Maximum Operating Temperature104°F (40°C)
Minimum Operating Temperature32°F (0°C)
Operating Humidity85%

Exposure
Longest Shutter Speed1/5 Second
Shortest Shutter Speed1/33500 Second

General Information
Brand NameAxis Communications
ManufacturerAxis Communications
Manufacturer Part Number02636-004
Product LineM
Product ModelM4327-P
Product NameM4327-P Panoramic Camera
Product SeriesM43
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length1.1 mm
Lens IncludedYes
Maximum Focal Length1.10 mm

Miscellaneous
Environmental CertificationREACH, RoHS
Environmentally FriendlyYes
Features2D Noise Reduction, 3D Digital Noise Reduction, Day/Night, Human Detection, Mirror, Noise Reduction, Privacy Masking, Vehicle Detection, Video Management System, White Balance, Wide Dynamic Range
Indoor/OutdoorIndoor
Package Contents M4327-P Panoramic Camera Installation guide Owner authentication key

Network & Communication
Remote ManagementYes

Others
ADI Part Number ReplacesZ4-01731001, Z4-01731004
Model Number Replaces01731-001M3067-P, 01731-004

Physical Characteristics
ColorWhite
Form FactorFisheye
Height2"
Weight (Approximate)10.58 oz

Product Information
Diameter4"
Mount TypeGang Box Mount, Junction Box Mount, Tripod Mount

Storage
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution6MP
Field of ViewHorizontal field of view: 182° Vertical field of view: 182°
HD RecordingYes
Lens TypeFixed
Maximum Aperturef/2.2
Maximum Frame Rate60 fps
Minimum Focal Length1.1 mm

Warranty
Limited Warranty5 Year
