Description

This ultra-compact fisheye camera offers 180°/360° panoramic coverage without blind spots, making it a superior choice for high-quality indoor surveillance. It integrates advanced analytics driven by edge-based deep learning technologies.

Superior Video Performance

The 12 MP fisheye camera provides a comprehensive view with exceptional sharpness and detail. It supports full 360° or 180° panoramic views and includes cutting-edge features like Lightfinder and Forensic WDR, ensuring vibrant colors and excellent detail in challenging lighting conditions. Its stereoscopic lens and digital PTZ capabilities allow users to customize view areas and zoom levels in up to four regions simultaneously. Built on the latest system-on-chip technology, it ensures enhanced image processing and superior picture quality.

Edge-Based Deep Learning

This indoor fisheye camera is equipped with a deep learning processing unit, enhancing processing and storage capabilities directly on the edge. Users can gather and analyze comprehensive data efficiently, both in real-time and in recorded footage. It provides valuable metadata for swift, effective forensic searches and supports object detection and classification through customizable analytics. With compatibility for advanced application platforms, users can enhance their systems with bespoke applications leveraging edge-based deep learning.

Sleek Design and Easy Installation

The discreet and affordable design ensures quick and hassle-free installation. It can be customized with optional casings and repainted to seamlessly integrate with any environment. Pre-focused from the factory, the camera also features digital roll functionality for remote adjustment of the camera’s view without manual intervention. Additionally, innovative technologies like Zipstream efficiently minimize bandwidth and storage demands while preserving image quality.

Camera
Wide Dynamic RangeYes

Certifications
TAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution3840 x 2160

Environmental Conditions
Maximum Operating Temperature104°F (40°C)
Operating Humidity85%

Exposure
Longest Shutter Speed1/2 Second
Shortest Shutter Speed1/8100 Second

General Information
Brand NameAxis Communications
ManufacturerAxis Communications
Manufacturer Part Number02637-004
Product LineM
Product ModelM4328-P
Product NameM4328-P Panoramic Camera
Product SeriesM43
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length1.2 mm
Lens IncludedYes
Maximum Focal Length1.20 mm

Miscellaneous
Environmental CertificationREACH, RoHS
Environmentally FriendlyYes
Features2D Noise Reduction, 3D Digital Noise Reduction, Day/Night, Human Detection, Mirror, Noise Reduction, Privacy Masking, Vehicle Detection, Video Management System, White Balance, Wide Dynamic Range
Indoor/OutdoorIndoor
Package ContentsM4328-P Panoramic Camera Installation guide Owner authentication key

Network & Communication
Remote ManagementYes

Others
ADI Part Number ReplacesZ4-01731004, Z4-01732004
Model Number Replaces01731-004, 01732-004

Physical Characteristics
ColorWhite
Form FactorFisheye
Height2"
Weight (Approximate)10.58 oz

Product Information
Diameter4"
Mount TypeBracket Mount, Gang Box Mount, Junction Box Mount, Tripod Mount

Storage
Recording Formats4K
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution12MP
Field of ViewHorizontal field of view: 182° Vertical field of view: 182°
HD RecordingYes
Lens TypeFixed
Maximum Aperturef/2.2
Maximum Frame Rate30 fps
Minimum Focal Length1.2 mm

Warranty
Limited Warranty5 Year
