Description

The PNM-9084QZ1 has been redesigned to be more compact and lightweight, facilitating easier installation even when using a ladder. Both the PNM-9084RQZ1 and PNM-9085RQZ1 feature remote PTRZ (Pan, Tilt, Rotate, and Zoom) functionality, significantly reducing the time and effort required for installers to make adjustments during setup. These models also come equipped with built-in IR sensors on each of their four lenses, allowing seamless movement of the lenses and IR sensors together. This ensures the delivery of clear images from distances of up to 30 meters, even in low-light conditions, providing enhanced security video surveillance.

Camera
Night Vision Distance98.43 ft
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66
TAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution1920 x 1080
Number of Sensors4

Environmental Conditions
Maximum Operating Temperature131°F
Minimum Operating Temperature-40°F
Operating Humidity

Exposure
Longest Shutter Speed2 Second
Shortest Shutter Speed1/12,000 Second

General Information
Brand NameHanwha Vision
ManufacturerHanwha Vision
Manufacturer Part NumberPNM-9084RQZ1/KUS
Product ModelPNM-9084RQZ1/KUS
Product Name8MP (2MP x 4) Multi-Sensor, Multi-Directional PTRZ Camera
Product SeriesP
Product TypeCamera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length3.2-10 mm
Lens IncludedYes
Maximum Focal Length10 mm
Minimum Aperturef/2.9

Miscellaneous
Features,, , NEMA4X, 2MP x 4 Channel multi-directional camera, using one IP address, 3.2-10mm(3.1x) motorized PTRZ varifocal lens, 60fps at 2MP(H.265, H.264), Easy Gangbox mounting installation, H.265, H.264, MJPEG codec, Multi streaming, Integrated IR that rotates with camera head, viewable length - 30m, Motorized PTRZ for easy installation and remote adjustment of entire FoV, Video analytics, WiseStreamII
Impact Protection RatingIK10

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorWhite
Color FamilyWhite
DurabilityDustproof, Impact Resistant, Waterproof
Product ColorWhite
Weight (Approximate)11.5 lb

Power Description
Input Voltage12V DC

Product Information
Diameter12.40"
Mount TypeDesktop Mount, Rack Mount, Wall Mount

Storage
Recording FormatsFull HD
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution8MP
Field of ViewH: 109.0°-33.2°, V: 57.4°-18.7°, D: 132.0°-38.0°
HD RecordingYes
Lens TypeVarifocal
Maximum ApertureF1.6
Maximum Frame Rate60 fps
Minimum Focal Length3.2 mm
Night VisionYes
Night Vision TypeInfrared
Optical Zoom3.2x

Warranty
Limited Warranty3 Year
