Description

The stainless steel fisheye camera, featuring the advanced Wisenet 7 technology, is equipped with a 1/2.3″ 12MP CMOS sensor delivering a 3008×3008 resolution at 30 FPS. It includes a 1.08mm fixed stereographic lens for enhanced peripheral resolution. Supporting H.265, H.264, and MJPEG codecs, this surveillance camera offers fisheye, single and double panorama, and quad view capabilities with onboard dewarping and digital PTZ. With extreme WDR (120dB), WiseStream support, Wise IR technology providing an IR viewable length of 26.2 feet (8 meters), this device is designed for robust video analytics, including features such as heatmap generation, people counting, and queue management. The rugged nylon dome encases the camera, which boasts IP66/IP67/IP6K9K/IK10+/NEMA4X ratings for durability and PoE or 12VDC power options. Additional features include virtual channel support, selectable I/O ports, and seamless handover functionality.

Camera
Night Vision Distance26'
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66, IP67, IP6K9K
TAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution1600 x 1200

Environmental Conditions
Maximum Operating Temperature122°F
Minimum Operating Temperature-40°F

Exposure
Longest Shutter Speed1/5 Second
Shortest Shutter Speed1/12000 Second

General Information
Brand NameHanwha Vision
ManufacturerHanwha Group
Manufacturer Part NumberXNF-9010RS
Product ModelXNF-9010RS
Product NameStainless Steel X series 12 MP sensor 360? Outdoor Fisheye
Product SeriesX
Product TypeNetwork Camera

Lens
Focal Length1.08 mm
Lens IncludedYes

Miscellaneous
FeaturesAudio Compression, Audio Detection, Back Light Compensation (BLC), Built-in IR LED, Day/Night, Digital Noise Reduction, Enter/Exit Detector, Gain Control, Highlight Compensation (HLC), Motion Detection, Privacy Masking, PTZ, SD Card Local Storage, Tamper Detection, White Balance, Wide Dynamic Range
Impact Protection RatingIK10
Indoor/OutdoorOutdoor

Network & Communication
Remote ManagementYes

Others
ADI Part Number ReplacesSQ-PN9002VQS
Model Number ReplacesPNM-9002VQS

Physical Characteristics
ColorWhite
DurabilityDustproof, Impact Resistant, Waterproof
Form FactorFisheye

Storage
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution12MP
Field of ViewH: 187° / V: 187° / D: 187°
HD RecordingYes
Lens TypeFixed
Maximum Aperturef/2.2
Maximum Frame Rate30 fps
Night VisionYes
Night Vision TypeInfrared
