Description

The AXIS P5655-E PTZ Network Camera is a high-performance and budget-friendly solution for versatile surveillance applications. Leveraging the latest generation of Axis processing technology, this camera delivers outstanding video quality even under difficult lighting conditions and offers robust security features to protect your surveillance system. It’s perfect for effective monitoring of expansive indoor and outdoor spaces and captures remarkable detail during zoom operations.

Exceptional Image Quality Anytime

The AXIS P5655-E ensures superb image quality in HDTV 1080p resolution with a 32x optical zoom capability. It features Forensic WDR for maintaining clarity in scenes with both dark and light areas and Lightfinder 2.0 for enhanced low-light images with more vibrant colors and sharper visuals of moving objects. Additionally, the camera includes electronic image stabilization (EIS) to ensure stable footage despite vibrations and focus recall for immediate focus under challenging lighting conditions. It is equipped with four scene profiles (indoor, outdoor, forensic, and traffic) with pre-optimized image settings tailored for specific situations.

Enhanced Security Features

This PTZ camera is equipped with advanced security measures to protect against unauthorized access and safeguard your surveillance system. Signed firmware and secure boot ensure that the firmware remains unaltered and authorize only verified firmware installation. Secure boot also guarantees the absence of malware after performing a factory reset.

Additional Capabilities

This adaptable camera complies with IP66, NEMA 4X, and IK10 standards, and can endure temperatures ranging from -30°C to 50°C (-22°F to 122°F). With its new generation chip, it provides enhanced processing power for executing advanced analytics. Utilizing Axis Zipstream technology with H.264 and H.265, it preserves critical details while significantly reducing bandwidth and storage needs. The camera also supports two-way audio, I/O ports, PoE+, and 24 V AC/DC.

Camera
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66
NDAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution1920 x 1080

Environmental Conditions
Maximum Operating Temperature122°F (50°C)
Minimum Operating Temperature-22°F (-30°C)
Operating Humidity100%

Exposure
Longest Shutter Speed2 Second
Minimum Illumination0.1 lux
Shortest Shutter Speed1/66500 Second

General Information
Brand NameAxis Communications
ManufacturerAxis Communications
Manufacturer Part Number01682-004
Product LineP
Product ModelP5655-E
Product NameP5655-E PTZ Network Camera
Product SeriesP56
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length4.3-137.6 mm
Lens IncludedYes
Maximum Focal Length137.60 mm
Minimum Aperturef/4

Miscellaneous
FeaturesAuto Gain Control, Automatic Defog, Cross Line Detection, Electronic Image Stabilization, HTTPS Encryption, Human Detection, Password Protection, Privacy Masking
Impact Protection RatingIK10
Indoor/OutdoorIndoor, Outdoor
Package ContentsP5655-E PTZ Network CameraRJ45 Push-pull Connector (IP66)Hard ceiling mountSpring pipe adaptorU-profile pipe adaptorInstallation Guideand more below, AVHS Authentication key, Windows decoder 1-user license

Network & Communication
Remote ManagementYes

Others
ADI Part Number ReplacesZ4-01682001
Model Number Replaces01682-001P5655-E

Physical Characteristics
ColorWhite
Color FamilyWhite
DurabilityDustproof, Impact Resistant, Waterproof, Weather Resistant
Form FactorDome
Height8.5"
Product ColorWhite
Weight (Approximate)5.51 lb

Power Description
Input Voltage100V AC, 240V AC

Product Information
Diameter7.4"
Mount TypeBracket Mount, Ceiling Mount, Corner Mount, Pendant Mount, Pole Mount, Recessed Mount, Wall Mount

Storage
Recording FormatsFull HD
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution2MP
Field of ViewHorizontal field of view: 58.3°- 2.4° - Vertical field of view: 35.5°- 1.4°
HD RecordingYes
Lens TypeVarifocal
Maximum Aperturef/1.4
Maximum Frame Rate60 fps
Minimum Focal Length4.3 mm
Optical Zoom32x

Warranty
Limited Warranty5 Years
