Description

### Superior IP Performance

The iconic EspritĀ® Series positioning system delivers cutting-edge image quality and outstanding pan/tilt performance in the surveillance industry. The Esprit Enhanced offers a comprehensive suite of superior imaging capabilities, advanced software features, and proven pan/tilt precision, making it ideal for a wide range of installation environments.

### Full HD SureVision 3.0 Cameras

Esprit Enhanced has set the standard with its Full HD 1080p 30x optical zoom camera. In its latest evolution, a robust new SureVision 3.0 enabled camera is now available, featuring an impressive 130dB True Wide Dynamic Range and dramatically improved low light performance, offering up to twenty times better clarity than previous models. This new camera module, available in standard or pressurized 30x optical zoom configurations, ensures superior image quality even in challenging outdoor environments. With the addition of an illuminator, these cameras deliver exceptional image clarity, even in the darkest conditions.

### Image Enhancement Features

Esprit Enhanced consistently integrates features that enhance the overall system value. With the addition of the SureVision 3.0 cameras, even more value is provided. Built-in video analytics, 32 window blanking privacy zones, and electronic image stabilization have been core features since the system’s inception, now enhanced with the latest camera technology.

### Standard IP Ethernet Connection and Integrated Transmission

Featuring dual form-factor pluggable transceivers for versatile connectivity options, including Fiber, Ethernet over Coax, and UTP Extension, Esprit Enhanced cameras excel in a wide range of network environments. With improved low light and wide dynamic range capabilities, SureVision 3.0 cameras also feature Image Defog, five advanced White Balance modes, and Vivid Imaging Mode for enhanced color saturation and sharpness. The three-stage Image Defog ensures optimal image clarity in foggy or rainy conditions, while the new White Balance modes tackle challenging lighting scenarios from external light sources like Sodium Vapor lamps.

### Proven Performance and Reliability

Combining superior enclosure design, precision PTZ mechanics, and state-of-the-art receiver technologies, Esprit Enhanced delivers an unmatched high-speed camera system within the industry. With over 16 years of global installations, the system continually evolves to offer the latest in pan/tilt and imaging excellence. It’s renowned for easy installation, intuitive operation, and dependable reliability.

### VMS Integration

Esprit Enhanced seamlessly integrates with various IP and hybrid video system configurations, including VideoXpert, Endura 2.0 (or later), and Digital Sentry 7.3 (or later). The camera also supports Digital Sentry NVS (DS NVS), a comprehensive video management software available for free with four complimentary IP licenses, enabling video management from up to 64 cameras.

Camera
Night Vision Distance656.17 ft
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66
NDAA CompliantYes

Display & Graphics
Color SupportedColor, Monochrome
Maximum Video Resolution1920 x 1080

Environmental Conditions
Maximum Operating Temperature140°F (60°C)
Minimum Operating Temperature-49°F (-45°C)
Operating Humidity90%

Exposure
Longest Shutter Speed1 Second
Shortest Shutter Speed1/10000 Second

General Information
Brand NamePelco by Motorola Solutions
ManufacturerMotorola Solutions, Inc.
Manufacturer Part NumberES6230-12-R2
Product ModelES6230-12-R2
Product NameEspirit Enhanced ES6230-12-R2 Network Camera
Product SeriesEsprit Enhanced
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length4.3-129 mm
Lens IncludedYes
Maximum Focal Length129 mm
Minimum Aperturef/1.6

Miscellaneous
FeaturesAuto Gain Control, Back Light Compensation (BLC), Day/Night, Digital Noise Reduction, Motion Detection, Privacy Masking, Wide Dynamic Range
Indoor/OutdoorIndoor, Outdoor

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorWhite
DurabilityDustproof, Waterproof, Weather Resistant
Form FactorBox Mount
Height20.9"
Weight (Approximate)35.01 lb
Width7.2"

Power Description
Input Voltage24V AC

Product Information
Length13.9"
Mount TypeCorner Mount, Pedestal Mount, Pole Mount, Wall Mount

Storage
Recording FormatsHD
Storage TypeMemory Card

Technical Information
Effective Camera Resolution2MP
Field of ViewHorizontal: 63.7 to 2.3°
HD RecordingYes
Lens TypeVarifocal
Maximum Aperturef/4.7
Maximum Frame Rate60 fps
Minimum Focal Length4.3 mm
Night VisionYes
Night Vision TypeInfrared
Optical Zoom30x
