Description

The renowned ESPRIT SERIES showcases an advanced positioning system, perfect for scenarios where visible surveillance acts as a deterrent against intrusion. This robust and reliable camera system excels in mission-critical environments where visible lighting is not suitable, where varying weather and lighting conditions are present, and where elevated coverage above the horizon is essential.

**Best Applications**:

– Securing the perimeter of correctional facilities and borders
– Ensuring uptime in airports, seaports, and refineries
– Monitoring military bases and high-security areas requiring swift camera response to aerial threats
– Enhancing security in urban areas and oil & gas operations within non-explosive zones

**Best-in-Class Camera Imaging**:

This trailblazing integrated solution delivers high-definition, high-speed positioning, unmatched weather resistance, and simplistic installation, setting a new benchmark in video surveillance.

Features include:

– Surevision 3.0 Technology with 130dB WDR
– Advanced Low Light Capacity down to 0.03 LUX, anti-bloom feature, 3D noise reduction, enhanced tone mapping
– Up to Full HD 1080p resolution with 60 fps
– Comprehensive built-in analytics like AutoTracker, adaptive motion detection, and abandoned object detection
– Defog mode offering three levels of fog removal for superior image quality under bad weather
– Vivid mode for enhanced image contrast and color saturation
– Electronic Image Stabilization (EIS)
– Integrated optics package or pressurized optics solution
– Dual stream H.264 IP video with smart compression
– Numerous preset options and tours
– Built-in window wiper with configurable settings on selected models
– Compliance with ONVIF Profile S, G, Q, and other standards
– Continuous 360° pan rotation at 140° per second
– SFP port compatibility with fiber optic modules
– Multi-power options: HPoE, 24VAC, 48VDC, or 100-240V

**Top-Tier IP Performance**:

Crafted from die-cast, extruded, and sheet aluminum with stainless steel hardware, this system features a durable gray polyester powder coat finish. Offering variable speed ranging from 0.1° to 140°, it maintains preset accuracy within ±0.1°. The system supports unobstructed vertical tilt from +40° to -90°, with 360° continuous pan rotation.

Camera
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66, IP67
NDAA CompliantYes

Display & Graphics
Color SupportedColor, Monochrome
Maximum Video Resolution1920 x 1080

Environmental Conditions
Maximum Operating Temperature140°F (60°C)
Minimum Operating Temperature-49°F (-45°C)
Operating Humidity100%

Exposure
Longest Shutter Speed1/1 Second
Shortest Shutter Speed1/10000 Second

General Information
Brand NamePelco by Motorola Solutions
ManufacturerMotorola Solutions, Inc.
Manufacturer Part NumberES6230-12P
Product ModelES6230-12P
Product NameEspirit Enhanced ES6230-12P Network Camera
Product SeriesEsprit Enhanced
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length4.3-129 mm
Lens IncludedYes
Maximum Focal Length129 mm
Minimum Aperturef/4.7

Miscellaneous
Features3D Noise Filtering, Alarm Triggering, Auto Gain Control, Auto Tracking, Back Light Compensation (BLC), Day/Night, Defog, Electronic Image Stabilization, Motion Detection, Password Protection, SD Card Local Storage, Wide Dynamic Range, Wiper
Impact Protection RatingIK06, IK07, IK10
Indoor/OutdoorIndoor, Outdoor

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorGray
DurabilityDustproof, Fog Resistant, Impact Resistant, Waterproof, Weather Resistant
Form FactorBox Mount
Weight (Approximate)29.89 lb

Power Description
Input Voltage24V AC, 48V DC

Product Information
Mount TypeCorner Mount, Pedestal Mount, Pole Mount, Wall Mount

Storage
Recording FormatsFull HD
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution2MP
Field of ViewHorizontal Angle of View - 63.7°(wide) - 2.3° (tele)
HD RecordingYes
Lens TypeVarifocal
Maximum Aperturef/1.6
Maximum Frame Rate60 fps
Minimum Focal Length4.3 mm
Optical Zoom30x
