Description

**Cost-Effective Solution**

The Pelco Spectra® Pro Series 2 is a cost-effective security camera solution suitable for a range of industry applications. It is designed for simplicity in ordering, installation, and operation, ensuring your focus remains on key organizational priorities.

**Full High Definition Surveillance**

Ideal for sectors like commercial, corrections, education, gaming, and healthcare, the Spectra Pro Series 2 provides extensive coverage with fewer cameras. It eliminates the need for manual PTZ oversight, offering low latency and smooth PTZ functionality for precise tracking. The camera’s 360° continuous pan and 30x optical zoom allow for detailed monitoring over large areas.

**Advanced Embedded Features**

All models in the Spectra Pro Series 2 come equipped with sophisticated video analytics, including Loitering Detection, Object Counting, Motion Detection, Camera Sabotage, and Audio Detection. They allow for up to 8 configurable privacy zones and offer Auto or Manual White Balance modes to tackle challenging lighting conditions. The series supports up to 2 TB of onboard local storage (not included) accessed via the ONVIF Profile G protocol or FTP.

**Efficient Video Encoding**

The Spectra Pro Series 2 offers three video encoding options: H.265 Main profile, H.264 High/Main/Baseline profiles, and MJPEG. The latest H.265 compression technology reduces bandwidth and storage demands by up to 70%, while preserving resolution and image quality critical for forensic analysis.

**User-Friendly Design**

Featuring intuitive installation and maintenance, the Spectra Pro Series 2 is compatible with various power options to seamlessly integrate with existing or new infrastructures.

**Comprehensive VMS Integration**

The Spectra Pro Series 2 integrates effortlessly with Pelco VideoXpert and provides limited compatibility with legacy systems like Endura 2.0 (or later) and Digital Sentry 7.3 (or later). Pelco is committed to being an open and integrated camera provider, ensuring the Spectra Pro Series 2 supports a wide and expanding range of third-party software and Video Management Systems (VMS).

Camera
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66, IP67
NDAA CompliantYes

Display & Graphics
Color SupportedColor
Maximum Video Resolution1920 x 1080

Environmental Conditions
Maximum Operating Temperature122°F (50°C)
Minimum Operating Temperature-40°F (-40°C)
Operating Humidity100%

Exposure
Longest Shutter Speed1/4 Second
Minimum Illumination0.1 lux
Shortest Shutter Speed1/30000 Second

General Information
Brand NamePelco by Motorola Solutions
ManufacturerMotorola Solutions, Inc.
Manufacturer Part NumberP2230L-EW1
Product LineSpectra
Product ModelP2230L-EW1
Product NameSpectra Pro Series 2 PTZ Camera
Product SeriesSpectra Professional 2
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length4.5-135 mm
Lens IncludedYes
Maximum Focal Length130 mm
Minimum Aperturef/1.6

Miscellaneous
Features3D Noise Filtering, Audio Compression, Audio Detection, Auto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Built-in Microphone, Day/Night, Digital Image Stabilization, HTTPS Encryption, Human Detection, Motion Detection, Password Protection, Privacy Protection, PTZ, Removable IR Cut-off Filter, SD Card Local Storage, Wide Dynamic Range
Impact Protection RatingIK10
Indoor/OutdoorOutdoor

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorWhite
DurabilityDustproof, Impact Resistant, Vandal Resistant, Waterproof
Form FactorDome
Weight (Approximate)6.15 lb

Power Description
Input Voltage24V AC, 48V DC

Product Information
Mount TypeCeiling Mount, Corner Mount, Pole Mount, Roof Mount, Wall Mount

Storage
Recording FormatsFull HD
Storage TypeMemory Card

Technical Information
Effective Camera Resolution2MP
Field of ViewHorizontal 59.8° (wide) ~ 2.34° (tele) Vertical 40.5° (wide) ~ 1.48° (tele) Diagonal 67.8° (wide) ~ 2.77° (tele)
HD RecordingYes
Lens TypeVarifocal
Maximum Aperturef/4.4
Maximum Frame Rate30 fps
Minimum Focal Length4.5 mm
Optical Zoom30x

Warranty
Limited Warranty3 Year
