Description

Leveraging the advanced Wisenet 7 chipset, the PTZ PLUS AI camera excels in the surveillance industry by offering sophisticated object detection and AI-powered auto-tracking for both persons and vehicles, featuring target lock tracking capabilities.

– Delivers 6MP resolution at 30 frames per second
– Infrared range extends up to 200 meters (656 feet)
– Equipped with a 30x optical zoom lens (5mm to 150mm), offering a field of view from 57.42° to 2.19°
– Integrated wiper and lens heater facilitate the removal of water and snow
– Capable of -20° tilt to view above horizon level
– Supports H.265, H.264, and MJPEG with triple codec functionality
– Enables multiple streaming, and is compatible with WiseStream III
– Features Day & Night functionality (ICR) and extreme Wide Dynamic Range (WDR)
– Digital Image Stabilization (DIS) with built-in gyro sensor
– Offers azimuth display for cardinal and intermediate directions
– Implements AI-driven object auto-tracking and intelligent video analytics
– AI analytics cover object detection, including person, face, vehicle, and license plate, with virtual line and area monitoring, directional analysis, and intrusion detection
– Provides advanced event analytics: defocus, motion, tampering, fog, and audio detection, along with sound classification using a network I/O box
– Dual memory slots accommodating up to 512GB each
– Durable design with IP66, IK10, NEMA4X, and NEMA TS-2 2.2.8 (vibration) & 2.2.9 (shock) ratings
– Supports High Power over Ethernet (HPoE) with IEEE802.3bt, Class6, Type3, including an injector
– Enhanced security with TPM 2.0 and FIPS 140-2 level 2 compliance
– Optional network I/O box available for alarm and audio integration
– Capable of operating in extreme temperatures ranging from -40°C to +55°C (-40°F to +131°F)

Camera
Night Vision Distance656.17 ft
Wide Dynamic RangeYes

Certifications
Ingress Protection RatingIP66

Display & Graphics
Color SupportedColor
Maximum Video Resolution1600 x 1200

Environmental Conditions
Maximum Operating Temperature131°F (55°C)
Minimum Operating Temperature-40°F (-40°C)
Operating Humidity95%

Exposure
Longest Shutter Speed2 Second
Shortest Shutter Speed1/12000 Second

General Information
Brand NameHanwha Vision
ManufacturerHanwha Group
Manufacturer Part NumberXNPC8303RW
Product ModelXNP-C8303RW
Product Name6MP 30x IR AI PTZ Camera with built-in wiper
Product SeriesX
Product TypeNetwork Camera

Interfaces/Ports
Network (RJ-45)Yes

Lens
Focal Length5-150 mm
Lens IncludedYes
Maximum Focal Length150 mm
Minimum Aperturef/4.56

Miscellaneous
FeaturesBack Light Compensation (BLC), Day/Night, Defog, Digital Image Stabilization, Digital Noise Reduction, Highlight Compensation (HLC), Motion Detection, PTZ, Shock Detection, Wide Dynamic Range
Impact Protection RatingIK10
Indoor/OutdoorOutdoor

Network & Communication
Remote ManagementYes

Physical Characteristics
ColorBlack, White
Color FamilyDual Color
DurabilityDustproof, Impact Resistant, Waterproof
Form FactorDome
Product ColorBlack, White
Weight (Approximate)12.35 lb

Product Information
Diameter7.3"
Mount TypeCeiling Mount, Corner Mount, Pendant Mount, Pole Mount, Wall Mount

Storage
Storage TypeMemory Card

Technical Information
Connectivity TechnologyWired
Effective Camera Resolution6MP
Field of ViewH: 57.42°(Wide)~2.19°(Tele) / V: 33.54°(Wide)~1.25°(Tele)
HD RecordingYes
Lens TypeVarifocal
Maximum Aperturef/1.6
Maximum Frame Rate30 fps
Minimum Focal Length5 mm
Night VisionYes
Night Vision TypeInfrared
Optical Zoom30x

Warranty
Limited Warranty3 Year
