Description

Enhance your enterprise network infrastructure with the second-generation UniFi Pro PoE 48-Port Gigabit Managed PoE Network Switch with SFP+ by Ubiquiti. This advanced Layer 3 switch is designed to meet the demanding needs of modern businesses, featuring passive cooling across 48 gigabit ports and a substantial 600W power budget. It includes 40 PoE ports providing 32W each and eight PoE++ ports offering 64W for power-hungry devices like high-resolution network security cameras. Experience seamless connectivity with 88 Gb/s non-blocking throughput, a 176 Gb/s switching capacity, and a forwarding rate of 130.94 Mpps. Additionally, the switch includes four 10 Gb/s SFP+ ports to facilitate expanded network integration using compatible devices. Network administrators can efficiently monitor and manage network operations through a 1.3″ touchscreen display or by utilizing the UniFi Network Controller application for comprehensive device management.

General Information
Brand NameUbiquiti
ManufacturerUbiquiti Inc.
Manufacturer Part NumberUSW-PRO-48-POE
Product LineUniFi
Product ModelUSW-PRO-48-POE
Product NameUbiquiti Networks UniFi Pro PoE 48-Port Gigabit Managed PoE Network Switch with SFP
Product SeriesUSW Pro
Product TypeNetwork Switch

I/O Expansions
Expansion Slot TypeSFP+
Number of SFP+ Slots4
Number of Total Expansion Slots4

Interfaces/Ports
ModularYes
Network (RJ-45)Yes
Port/Expansion Slot Details4 x 10 Gigabit Ethernet Expansion Slot, 40 x Gigabit Ethernet PoE+, 8 x Gigabit Ethernet PoE++
Total Number of Network Ports48
Uplink PortYes

Management & Protocols
ManageableYes

Media & Performance
Network Technology10/100/1000Base-T, 10GBase-X

Miscellaneous
Environmentally FriendlyYes
Features176 Gb/s Switching Capacity, 4 x 10 Gb/s SFP+ Ports, 40 x PoE+ Ports and 8 x PoE++ Ports, 48 x Gigabit Ethernet Ports, Near-silent cooling, The second-generation UniFi switch offers a 130.94 Mpps forwarding capacity to simultaneously process traffic on all ports without packet loss. The UniFi PoE Pro Switch has a non-blocking throughput of 88 Gb/s with a 176 Gb/s switching capacity., The UniFi Pro PoE Switch supports has an external DC power interface, which works with a separate power adapter as a power backup if the internal PSU fails
Package Contents USW-Pro-48-PoE Layer 3 Switch Rack Mount Hardware

Network & Communication
Ethernet Technology10 Gigabit Ethernet
Layer Supported3
Networking StandardsIEEE 802.3af, IEEE 802.3at, IEEE 802.3bt

Physical Characteristics
Compatible Rack Unit1U
Depth15.7"
Form FactorRack Mount
Height1.7"
MaterialSGCC Steel
Product MaterialGalvanized Cold Rolled Steel (SGCC)
Weight (Approximate)14 lb
Width17.4"

Power Description
Frequency50/60 Hz
Input Voltage100-240V AC
PoE (RJ-45) PortYes
PoE Budget600W
Power SourceAC, DC
Redundant Power Supply SupportedYes

Technical Information
Media Type SupportedOptical Fiber, Twisted Pair
PoEYes
Power Consumption60W

Warranty
Limited Warranty1 Year
