Description
The Hanwha Vision HRX-1635-36TB is a 16-channel pentabrid DVR equipped with a 36TB hard disk drive, designed for robust video surveillance solutions in the security industry.
Hanwha HRX-1635-36TB 5-in-1 16-Channel Pentabrid DVR, 36TB
In Stock
Special Order
$3,480.43
- 5-in-1 16-Channel Pentabrid Digital Video Recorder (DVR)
- Supports AHD, HDTVI, HDCVI, CVBS, and IP Inputs
- Total 18-Channel Configuration (Up to 16 Analog Channels plus Network Options from 2 up to 18 Channels, depending on Analog Usage), supports resolutions up to 8MP
- Compatible with H.265, H.264, and MJPEG Codecs
- Records Analog Cameras at 8MP (15 fps), 5MP (20 fps), 4MP (30 fps), 2MP (30 fps), 1MP (30 fps), and 960H (or 720H) (30 fps) per Channel
- Maximum Recording Bandwidth of 128 Mbps and Playback Bandwidth of 32 Mbps
- Includes 4-Channel Audio Input and 1-Channel Audio Output, 16 Alarm Inputs and 4 Relay Outputs
- Features Coaxial Control
- Supports Up to 2 SATA HDDs (6TB per HDD)
- Offers HDMI/VGA Video Output and 1 Spot Monitor Output
SKU:
HRX-1635-36TB
Categories: Recording Devices, Video Surveillance, Video Surveillance DVRs
Brand: Hanwha Vision
| Audio | |
| Mobile Operating System Compatibility | iOS|Android |
| Display & Graphics | |
| Maximum Video Resolution | 3840 x 2160 |
| General Information | |
| Brand Name | Hanwha Vision |
| Manufacturer | Hanwha Group |
| Manufacturer Part Number | HRX-1635-36TB |
| Product Model | HRX-1635 |
| Product Name | 16CH Pentabrid DVR |
| Product Series | HRX |
| Product Type | Video Surveillance Station |
| Interfaces/Ports | |
| HDMI | Yes |
| Number of USB Ports | 3 |
| USB | Yes |
| Miscellaneous | |
| Environmental Certification | UL |
| Network & Communication | |
| Ethernet | Yes |
| Physical Characteristics | |
| Color | Black |
| Color Family | Black |
| Depth | 15.1" |
| Height | 3.5" |
| Width | 17.3" |
| Power Description | |
| Input Voltage | 12V DC |
| Maximum Power Consumption | 40W |
| Storage | |
| Hard Drive Capacity | 36TB |
| Technical Information | |
| HD Recording | Yes |
| Maximum Frame Rate | 30 fps |
| Number of Channels | 16 |
| Storage Capacity | 36TB |
| Video Signal Format | NTSC, PAL |
| Warranty | |
| Limited Warranty | 3 Year |
